• Model NO.：CPD20FVD
• Lift height：3000-6000mm
• Condition：New
• Certification：Ce
• Operator Type：Seated
• Structure Weight：3540kg
• Tyre Type：Solid Rubber
• Height,Mast Lowered：2060mm
• Turning Radius：1715mm
• Travel Speed：13,14 Km,H
• Lifting Speed：0.26,0.43
• Service Brake：Mechanical,Hydrualic
• Battery Voltage：City: 48V,500ah
• Transport Package：Standard Export Packing
• Specification：L3172mm*W1150mm*H2112
• Trademark：EP
• Origin：China
• HS Code：8427109000
• Production Capacity：4000

Basic Info.

Model NO. CPD20FVD Lift height 3000-6000mm Condition New Certification Ce Operator Type Seated Structure Weight 3540kg Tyre Type Solid Rubber Height,Mast Lowered 2060mm Turning Radius 1715mm Travel Speed 13/14 Km/H Lifting Speed 0.26/0.43 Service Brake Mechanical/Hydrualic Battery Voltage City: 48V/500ah Transport Package Standard Export Packing Specification L3172mm*W1150mm*H2112 Trademark EP Origin China HS Code 8427109000 Production Capacity 4000

Product Description

Distinguishing mark
1.1	Manufacturer			EP	EP
1.2	Model designation			CPD18FVD	CPD20FVD
1.3	Drive unit			Electrics	Electrics
1.4	Operator type			seated	seated
1.5	rated capacity	Q	t	1.8	2.0
1.6	Load center distance	c	mm	500	500
1.8	Load distance,centre of drive axle to fork	x	mm	397.5	397.5
1.9	Wheelbase	y	mm	1435	1435
Weight
2.1	Service weight (include battery)		kg	3440	3540
2.2	Axle loading, laden driving wheels /steering wheels		kg	4625/615	4955/585
2.3	Axle loading, unladen  driving wheels /steering wheels		kg	1720/1720	1720/1820
Types,Chassis
3.1	Tyre type,driving wheels /steering wheels			solid rubber	solid rubber
3.2	Tyre size, driving wheels			18X7-8	200X50-10
3.3	Tyre size, steering wheels			16X6-8	16X6-8
3.5	Wheels, number driving/steering (x=drive wheels)		mm	2x/ 2	2x/ 2
3.6	Tread, Driving wheels	b10	mm	902	902
3.7	Tread, Steering wheels	b11	mm	890	890
Dimensions
4.1	Tilt of mast/fork carriage forward/backward	α/ β (°)		5/5	5/5
4.2	Height, mast lowered	h1	mm	2112	2112
4.3	Free lift (load backrest)	h2	mm	120	120
4.4	Lift height	h3	mm	3000	3000
4.5	Height, mast extended	h4	mm	4058	4058
4.7	Height of overhead guard (cabin)	h6	mm	2112	2112
4.8	Seat height	h7	mm	1052	1052
4.12	Tow center of pin height	h10	mm	527	527
4.19	Overall length	l1	mm	3022	3022
4.20	Length to face of forks	l2	mm	2102	2102
4.21	Overall width	b1/ b2	mm	1090	1150
4.22	Fork dimensions	s/ e/ l	mm	40×100×920	40×100×920
4.23	Fork carriage class/type A, B			A	A
4.24	Fork carriage width	b3	mm	1040	1040
4.31	Ground clearance, laden, below mast	m1	mm	130	130
4.32	The minimum ground clearance of frame	m2	mm	130	130
4.34.1	Aisle width for pallets 1000 × 1200 crossways	Ast	mm	3436	3436
4.34.2	Aisle width for pallets 800 × 1200 lengthways	Ast	mm	3562	3562
4.35	Turning radius	Wa	mm	1715	1715
Performance data
5.1	Travel speed, laden/ unladen		km/ h	13/ 14	13/ 14
5.2	Lifting speed, laden/ unladen		m/ s	0.27/ 0.43	0.26/ 0.43
5.3	Lowering speed, laden/ unladen		m/ s	0.44/ 0.435	0.44/ 0.435
5.5	Drawbar pull, laden/unladen		N
5.6	Max. drawbar pull, laden/unladen (time)		N	/	/
5.7	Gradeability, laden/unladen		%	10.5/ 14.5	10.5/ 14.5
5.8	Max. gradeability, laden/unladen		%
5.10	Service brake type			Hydraulic / Mechanical	Hydraulic / Mechanical
	park brake type			Hydraulic / Mechanical	Hydraulic / Mechanical
Electric-engine
6.1	Drive motor rating S2 60 min		kW	4.8x2	4.8x2
6.2	Lift motor rating at S3 15%		kW	11	11
6.3	The maximum allowed size battery		mm	/	/
6.4	Battery voltage/nominal capacity K5			48/500	48/500
6.5	Battery weight		kg	856	856
Addition data
8.1	Type of drive unit			AC	AC
10.5	Steering type			Hydraulic / Mechanical	Hydraulic / Mechanical
10.7	Sound pressure level at the driver's ear		dB (A)	70	74
