• Model NO.：MF
• Condition：New
• Certificate：ISO9000
• Capacity：1000kg-3000kg
• Material：Steel
• Style：Double Faced
• Entry Type：2-Way
• Transport Package：Nude Package
• Specification：2089*1084mm
• Trademark：MIMA
• Origin：China
• HS Code：8427109000
• Production Capacity：5000 Units , Year

  Electric reach truck  2  Model  MF20  MF25  MF30  3   Load capacity           2000  2500  3000  4  Load center   500  500  500  5  Lifting height       3000  3000  3000  6  Tilting angle (forward- backward)  3/5  3/5  3/5  7  Wheel type Polyurethane  solid tire  8  Mast forwarding length  717  825  925  9  Fork size  1070x100x40  1070x100x45  1070x125x45   10  Fork outside width  222-750  222-750  250-750  11  Overall length(with forks)  2293  2387  2487  12  Overall width       1090/1170  1190/1270  1190/1270  13  Mast closed height   2082  2082  2082  14  Overall height fork raised(with backrest)  3960  3960  3960  15  Overhead guard height   2250  2300  2300  16  Turning radius  1784  1784  1784  17  Aisle width for pallet 1000*1200mm  2750  2894  3045  18  Aisle width for pallet 800*1200mm  2762  2762  2762  19  Lifting speeds (Loaded/ Unloaded)  220/380  240/320  220/320  20  Max. gradeability  ≤ 10  ≤ 10  ≤ 10  21  Total weight( with battery)  2750  3300  3400  22  Driving wheel   Φ 343*108  Φ 380*165  Φ 380*165  23  Loading wheel   Φ 254*104  Φ 267*135  Φ 267*135  24  Balance wheel   Φ 180*76  Φ 204*76  Φ 204*76  25  Mast clearance    82   82   82  26  Brake type  mechanical  27  Battery  48/300   48/400  48/400  28  Charger  48/40  48/50  48/50  29  Driving motor  5.5(AC)  5.5(AC)  5.5(AC)  30  Lifting motor  6.3  7.5  7.5  31  Steering system  EPS

Why choose us

BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO., LTD.
        Founded in 1994, BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO.,LTD is located in Hefei, Eastern of China. As the leading manufacturer of Chinese electric forklift and material handling equipment, we are specialized in designing and developing with all-around logistics handling solutions. We have passed not only ISO9001:2008, ISO14001:2004 and CE certifications, but also got the People's Republic of China Special Equipment Production License and the honor of "Innovative Enterprise".
    Referring to 12 series and more than 50 kinds of products, MiMA can offer you with electric forklift, electric reach truck, pallet stacker, pallet truck, order picker, tow tractor, narrow aisle forklift, special forklift, AGV and other customized equipments, which can provide customers with logistics handling solutions from 500kg to 100,000kg. Due to serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
    Owing to 100 national service networks and dozens of foreign dealers, we promise customers with competitive prices and perfect after-sales service. We are looking forward to better cooperation all over the world.

Our workshop and warehouse




Many of our models are in stock, for more details please feel free to contact us.

Exhibition
