Mima 2 Ton Reach Stacker Seated Type
Banyitong Science & Technology Developing Co., Ltd.- Type：Stacker
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Electric
- Load center：500mm
- Lift height：>5000mm
Base Info
- Condition：New
- Certificate：ISO9000
- Capacity：1600-2000kg
- Material：Steel
- Style：Double Faced
- Transport Package：Nude Package
- Specification：2355*1290mm
- Trademark：MIMA
- Origin：China
- HS Code：8427109000
- Production Capacity：5000 Units , Year
Description
Seated On Type Electric ReachTruck Model MFZ16 MFZ16SQ MFZ20 MFZ20SQ Load capacity kg 1600 1600 2000 2000 Load center mm 500 500 500 500 Lift height mm 3000 7500 3000 7500 Tilting angle (forward- backward) α/β(°) 3/5 3/5 3/5 3/5 Mast closed height mm 2175 3250 2175 3250 Wheel type Polyurethane PU Reach stroke mm 583 583 617 617 Fork size mm 1070*100*35 1070*100*35 1070*122*40 1070*122*40 Fork outside width mm 220-750 220-750 222-772 222-772 Overall length mm 2355 2340 2431 2421 Overall width mm 1290 1290 1290 1290 Mast closed height mm 2175 3250 2175 3250 Mast extended height (with backrest) mm 3970 8470 3970 8470 Overhead guard height mm 2200 2200 2200 2200 Turning radius mm 1700 1700 1798 1798 Aisle width for pallet 1000*1200mm mm 2771 2764 2845 2845 Aisle width for pallet 800*1200mm mm 2823 2814 2891 2882 Driving speeds (Loaded/ Unloaded) km/h 8.5/10 8.5/10 8.5/10 8.5/10 Lifting speeds (Loaded/ Unloaded) mm/s 210/340 210/340 210/340 210/340 Driving motor(S2-60min) kw 5.5 5.5 5.5 5.5 Lifting motor(S3-15%) kw 8.6 8.6 8.6 8.6 Total weight( with battery) kg 3250 3710 3246 4000 Brake type Mechanical Steering system EPS
Why choose us
BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO., LTD.
Founded in 1994, BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO.,LTD is located in Hefei, Eastern of China. As the leading manufacturer of Chinese electric forklift and material handling equipment, we are specialized in designing and developing with all-around logistics handling solutions. We have passed not only ISO9001:2008, ISO14001:2004 and CE certifications, but also got the People's Republic of China Special Equipment Production License and the honor of "Innovative Enterprise".
Referring to 12 series and more than 50 kinds of products, MiMA can offer you with electric forklift, electric reach truck, pallet stacker, pallet truck, order picker, tow tractor, narrow aisle forklift, special forklift, AGV and other customized equipments, which can provide customers with logistics handling solutions from 500kg to 100,000kg. Due to serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.
Owing to 100 national service networks and dozens of foreign dealers, we promise customers with competitive prices and perfect after-sales service. We are looking forward to better cooperation all over the world.
Our workshop and warehouse
Many of our models are in stock, for more details please feel free to contact us.
Exhibition
