Hydraulic 4 Ton Material Handling Diesel Forklift Truck with Side Shift
Xiamen Hifoune Technology Co., Ltd.- Cab Location：Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
- Fuel：Diesel
- Load center：500mm
Base Info
- Model NO.：FD40T
- Lift height：>5000mm
- Condition：New
- Engine：Xinchai,Isuzu,Mitsubish
- Weight：3440kg
- Rated Capacity：4000kg
- Fork Size：1220X122X40mm
- Transmission Box Type：Automatic Transmission
- Tire Type：Pneumatic Tire
- Warranty：One Year or 2000hours
- Transmission：Hydraulic
- Optional：Attachment,Side Shifter, Sealed Cab, Mast, etc
- Mast：Duplex Mast (Triplex Mast Optional)
- Color：Customized
- Certification：CE,ISO
- Transport Package：Container
- Specification：3640x1150x2125mm(LXWXH)
- Trademark：Hifoune
- Origin：Cn
- HS Code：8427109000
- Production Capacity：4500sets,Year
Description
ModelUNIT FD40T Specifications Power Unit Diesel Operator Type Driver/Seat Transimission Box Type Automatic Transimission Rated Capacity kg 4000 Load Center mm 500 Max.Lifting Height mm 3000 Tire Type Pneumatic Tire Tire Number Front 2 Rear 2 Tire Size Front 250-15-16PR Rear 6.5-10-10PR Performance Lifting Speed Loaded mm/s 430 Unloaded 480 Lowering Speed Loaded mm/s 400 Unloaded 380 Travelling Speed Loaded km/h 20 Unloaded 21 Max.Gradeability (Loaded) % 20 Max.Drawbar Pull (Loaded) kn 18 Mast Tilting Angle (Fwd/Bwd) deg 6/12 Free Lifting Height mm 150 Turning Radius mm 2560 Dimensions Overall Length (with fork) mm 3930 Overall Width mm 1300 Overhead Guard Height mm 2155 Fork Size (LxWxT) mm 1220×150×50 Mast Height (Fork lowered) mm 2140 Battery (Voltage/Capacity) V/Ah 12/90 Truck Weight kg 4900 Fuel Tank Capacity L 70 Engine Brand XINCHAI ISUZU MITSUBISH Model C498 4JG2 S4S Rated Power kw/rpm 42/2650 44.8/2450 35.3/2250 Rated torque n-m/rpm 174/1600 186/1800 169/1700 Number Of Cylinder 4 4 4 Displacement 2.8 3.06 2.49
Shipping & Packing
About us
Xiamen Hifoune Machinery Co., Ltd. is located in the Xiangan industrial zone of Xiamen torch high tech Zone. It is dedicated to providing reliable and efficient material handling equipment and solutions for customers. It is a professional company integrating R & D, manufacturing, sales and service. Our main products include a full range of internal combustion counterbalanced forklift trucks, electric counterbalance forklift trucks, and electric warehouse equipment. We not only aim to provide excellent products to customers in our full range of products, but also provide excellent service to customers in all links
