• Model NO.：CPCD30
• Fuel：Diesel
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Mast Overall Height：2090mm
• Max. Fork Lifting Height (with Backrest)：3000mm
• Overall Height (Overhead Guard)：2150mm
• Tyre Type：Pneumatic Tyre
• Frok Size (Lxwxh)：1070X125X45mm
• Total Weight：4300kg
• Transport Package：by Roro, Bulk Cargo or Container Transprot
• Specification：3 Ton
• Trademark：Heli
• Origin：Anhui, China
• HS Code：8427209000
• Production Capacity：50 Uint, Month

Model  CPCD30 Power type Diesel Rated capacity kg 3000 Load center mm 500 Max. Lift height mm 2065 Max.fork lift height(with backrest) mm 4262 Free lift height mm 160 Fork size(L3xWxH) mm 1070×125×45 Mast tilting angle ° 6/12 Front/Rear overhang mm 479/495 Min.ground clearance mm 135 Overall Length to face of forklift mm 2065 Overall width mm 1225 Overall length(with/without fork) mm 3752/2682 Backrest height mm 1227 Overhead guard height mm 2070 Traction pin height mm 310 Wheel base mm 1700 Turning radius(exterior/interior) mm 2400/200 Min.right angle aisle width mm 2380 Speeds Drive speeds km/h 18/19 Lifting speeds mm/s 440/480 Lowering speeds mm/s 450/500 Max.Drawbar pull KN 21/16 Max.grade ability % 20/20 Total weight kg 4270 Tires Wheel no.X=drive wheel 2x/2 Front 28*9-15-12PR Rear 6.5-10-10PR Service brake Hydraulic foot pedal lever Parking brake Mechanical hand lever Tread Front mm 1000 Rear mm 970 Engine   Model QUANCHAI QC490GP Rated output Kw/rpm 39/2650 Rated torque N.m/rpm 162/1950 No.of cylinder4 Displacement L 2.54 Gearbox F/RT/M 1-1 Power shift T/M  T/M 2-2 Manual shift T/M Fuel tank capacity L 60










Our company

Newindu Construction Engineering (Shanghai) Co., Ltd. is professional in construction machinery for nearly 10 years, exporting with good quality and low price, having excavator, truck crane, bulldozer, wheel loader, motor grader, drilling rig, dump truck, road roller, forklift, reach stacker, and also including the spare parts, etc.
