• Model NO.：CPCD300
• Load Capacity：18T - 42T
• Fuel：Diesel
• Load center：>500mm
• Lift height：3000-6000
• Condition：New
• Tire Type：Pneumatic
• Certification：CE,ISO
• Fork Size：1150,1220 mm
• Weight：39500kg
• Color：Orange,Yellow,Red
• Engine：Optional
• Wheel Base：4800 mm
• Lifting Speed：260 mm,Sec
• Transmission：Hydraulic,Mechanical
• Transport Package：Naked
• Specification：2698*1225*2090mm
• Trademark：GP
• Origin：China
• HS Code：8427209000
• Production Capacity：500 Units,Month
• Package size per unit product：269.80cm * 122.50cm * 209.00cm
• Gross weight per unit product：39500.000kg

Basic Info.

Model NO. CPCD300 Load Capacity 18T - 42T Fuel Diesel Load center >500mm Lift height 3000-6000 Condition New Tire Type Pneumatic Certification CE,ISO Fork Size 1150/1220 mm Weight 39500kg Color Orange,Yellow,Red Engine Optional Wheel Base 4800 mm Lifting Speed 260 mm/Sec Transmission Hydraulic/Mechanical Transport Package Naked Specification 2698*1225*2090mm Trademark GP Origin China HS Code 8427209000 Production Capacity 500 Units/Month

Packaging & Delivery

Package size per unit product 269.80cm * 122.50cm * 209.00cm Gross weight per unit product 39500.000kg

Product Description

Specific parameters

1. Three alternatives of engine: Imported Isuzu C240, Yanmar 4TNE92/94/98 engine, and domestic Xinchai 490/495. Economical but powerful enough

2. Transmission: With TCM technology.

3. Man-machine engineering designs, including the floating shock absorber configured on the engine, the elastic linked steering axle, the redirector providing low tensional moment, the semi-floating bonnet with built-in heat and sound insulation, ensure the comfort of driving.

4. The optional imported engines meet EU stage-III mission control regulation and obtain EPA accreditation.
