• Model NO.：ES15-15ES
• Lift height：3230
• Condition：New
• Rated Loading Capacity：1500kg
• Max. Lifting Height：3230mm
• Min. Lifting Height：88mm
• Fork Length：920mm
• Fork Width：170mm
• Service Weight：755kg
• Tyre Type：PU
• Travel Speed：5 Km,H
• Lifting Speed：0.13,0.2 M,S
• Battery Voltage：24V,125ah
• Transport Package：Standard Export Packing
• Specification：1740mm*800mm*2128mm
• Trademark：EP
• Origin：Zhejiang
• HS Code：8427109000
• Production Capacity：50000,Year

Basic Info.

Model NO. ES15-15ES Lift height 3230 Condition New Rated Loading Capacity 1500kg Max. Lifting Height 3230mm Min. Lifting Height 88mm Fork Length 920mm Fork Width 170mm Service Weight 755kg Tyre Type PU Travel Speed 5 Km/H Lifting Speed 0.13/0.2 M/S Battery Voltage 24V/125ah Transport Package Standard Export Packing Specification 1740mm*800mm*2128mm Trademark EP Origin Zhejiang HS Code 8427109000 Production Capacity 50000/Year

Product Description

Specification:

Distinguishing mark
1.1	Manufacturer			EP	EP
1.2	Model designation			ES15-15ES	ES15-18ES
1.3	Drive unit			Electric	Electric
1.4	Operator type			Pedestrian	Pedestrian
1.5	rated capacity	Q	kg	1500	1800
1.6	Load center distance	c	mm	600	600
1.8	Load distance,centre of drive axle to fork	x	mm	805	805
1.9	Wheelbase	y	mm	1240	1240
Weight
2.1	Service weight (include battery)		kg	755	773
2.2	Axle loading, laden driving side/loading side		kg	805/1450	858/1715
2.3	Axle loading, unladen  driving side/loading side		kg	545/210	558/215
Types,Chassis
3.1	Tyre type Driving wheels/Loading wheels			PU/PU	PU/PU
3.2	Tyre size, driving wheels(diameter×width)		mm	Ф230×75	Ф230×75
3.3	Tyre size, loading wheels(diameter×width)		mm	Ф80×60	Ф80×60
3.4	Tyre size, caster wheels(diameter×width)		mm	Ф130×55	Ф130×55
3.5	Wheels, number driving,caster/loading (x=drive wheels)		mm	1x +2/4	1x +2/4
3.6	Track width, front,driving side	b10	mm	538	538
3.7	Track width,rear,loading side	b11	mm	400	400
Dimensions
4.2	Height, mast lowered	h1	mm	2128	2128
4.3	Free lift	h2	mm
4.4	Lift height	h3	mm	3230	3230
4.5	Height, mast extended	h4	mm	3743	3743
4.9	Height drawbar in driving position min./max.	h14	mm	1150/1480	1150/1480
4.15	Lowered height	h13	mm	88	88
4.19	Overall length	l1	mm	1740	1740
4.20	Length to face of forks	l2	mm	575	575
4.21	Overall width	b1	mm	800	800
4.22	Fork dimensions	s/ e/ l	mm	60×170×1150	60×190×1150
4.24	Fork carriage width	b3	mm	680	795
4.25	Distance between fork-arms	b5	mm	570	685
4.32	Ground clearance, center of wheelbase	m2	mm	28	28
4.34.1	Aisle width for pallets 1000 × 1200 crossways	Ast	mm	2340	2340
4.34.2	Aisle width for pallets 800 × 1200 lengthways	Ast	mm	2260	2260
4.35	Turning radius	Wa	mm	1500	1500
Performance data
5.1	Travel speed, laden/ unladen		km/ h	5/5	5/5
5.2	Lifting speed, laden/ unladen		m/ s	0.13/0.2	0.13/0.2
5.3	Lowering speed, laden/ unladen		m/ s	0.13/0.13	0.13/0.13
5.8	Max. gradeability, laden/unladen		%	8/16	8/16
5.10	Service brake type			Electromagnetic	Electromagnetic
Electric-engine
6.1	Drive motor rating S2 60 min		kW	1.27	1.27
6.2	Lift motor rating at S3 15%		kW	3	3
6.3	The maximum allowed size battery		mm	330x190x240	330x190x240
6.4	Battery voltage/nominal capacity K20		V/ Ah	2x12/125	2x12/125
6.5	Battery weight		kg	60	60
Addition data
8.1	Type of drive unit			AC	AC
10.5	Steering type			Machanical	Machanical
10.7	Sound pressure level at the driver's ear		dB (A)	74	74
