• Model NO.：FG35
• Fuel：Gasoline
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Power Type：LPG&Gasoline
• Fork Size：1070mm*125mm*50mm
• Weight：4610kg
• Wheelbase：1700mm
• Tire Type：Pneumatic
• No. of Cylinder：4
• Transmission：Hydraulic
• Color：Customize
• Transport Package：Container
• Specification：2720mm*1285mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

Model Power shift T/MFG35Manual shift T/MFG35Load capacity kg3500Load center mm500Power unit  GasolineOperator type  Driver/seatTire typeFront/rear PneumaticWheelFront/rear 2/2Max. lifting height mm3000Free lift mm150Fork sizeL*W*Tmm1070*125*50Tilt rangeMast forward/backwarddeg6/12Overall length(without fork) mm2720Total width mm1285Mast height (fork lowering) mm2075Overall height fork raisedWith backrestmm4250Height to head guard mm2140Turning radius(outside) mm2460Front face of fork to front axle mm485Min. right angle stacking aisle  without load length&clearancemm2940SpeedMax Travelling full/no loadkm/h18/19.5Lifting full/no loadmm/s450/500Lowering full/no load mm/s450/420Max.drawbar pullPower shift T/M full/no loadkg1800/1000Manual shift T/M full/no loadkg1900/1000Gradeability at 1.6km/hPower shift T/M full/no load%17/20Manual shift T/M full/no load%17/20Truck weight kg4610Weight  distributionFull load front/rearkg7260/850No load front/rearkg1840/2770TiresNumberfront/rear2/2Modelfront axle28x9-15-12PRrear axle6.50-10-10PRWheelbase mm1700TreadFront/rearmm1060/970Ground clearanceAt lowest point(mast)mm120Framemm135BrakeService  brake Hydraulic-foot pedalParking brake Mechanical-hand leverBatteryVoltage/capacityV/AH12/60EngineRated powerPS(kw/rpm)51/2300(37.4/2300)Rated torquekg-m    max.(N.m)18/1600(177/1600)Number of cylinders 4PlacementL2.488Fuel tank capacityL70TransmissionSpeed forward/backwardPower shift T/M Manual shift T/M1-1 power shift T/M 2-2 power shift T/MOperating pressureHydraulic system pressurekg/cm²180
