• Model NO.：FD100Z
• Fuel：Diesel
• Load center：>500mm
• Lift height：3000~5000mm
• Condition：New
• Rated Loading Capacity：10000kg
• Max. Lifting Height：3000mm
• Fre Lifting Height：208mm
• Forks(L*W*H)：1520*175*85mm
• Min.Turning Radius：3970mm
• Engine：Weichai,Shangchai,Cummins
• Transport Package：Container
• Specification：3431*2235*2500mm
• Trademark：Zoomlion
• Origin：China
• HS Code：842720900
• Production Capacity：100pieces,Month

Model FD40FD50FD60FD70FD100Brand(OEM acceptable) FLIFTFLIFTFLIFTFLIFTFLIFTPower Source DieselDieselDieselDieselDieselCapacitykg400050006000700010000Load centermm500600600600600Lift height(Duplex wide-view)mm30003000300030003000Fork size(LxWxH)mm1070*150*501220*150*601220*150*601220*150*701520*175*85Mast tilt angle(F/R)Deg6°/12°6°/12°6°/12°6°/12°6°/12°Length to face of forkmm32203450345035604280Overall widthmm14802010201020102170Mast lowered heightmm23502500250025002850Mast extended heightmm42504380438043804300Overhead guard heightmm23202470247024702570Turning radiusmm29003250325033503970Min. right angle aisle widthmm29202960296030403590Wheelbasemm21002250225022502800Lifting (full load)mm/s460500500460270Gradeability(laden)%2020202020Service weightkg645085509150975013100Front tire 300-15-18PR8.25-15-14PR8.25-15-14PR8.25-15-14PR9.00-20-14PRRear tire 7.00-12-12PR8.25-15-14PR8.25-15-14PR8.25-15-14PR9.00-20-14PRBattery (voltage/capacity)v/ah(12V/80Ah)(12V/80Ah)*2(12V/80Ah)*2(12V/80Ah)*2(12V/80Ah)*2Engine model A498BPG-571isu-6BG1isu-6BG1isu-6BG1isu-6BG1Engine rated torque/r.p.m.n.m193/1600-1800416/1400-1600416/1400-1600416/1400-1600416/1400-1600Displacementcc31706494649464946494Fuel tank capacityL60140140140140
More pictures:



Our factory
