Famous Brand Hh30z 3m Lifting Height 3 Ton Mini Diesel Forklift
Cruking Engineering Equipment (Xiamen) Co., Ltd.- After-sales Service:Video Technical Support, Online Support
- Warranty:1 Year
- Cab Location:Adjustable
- Type:Diesel Forklift
- Power:Diesel Engine
- Load Capacity:3 Ton
Base Info
- Model NO.:HH30Z
- Fuel:Diesel
- Load center:500mm
- Lift height:3000~5000mm
- Condition:New
- Free Lift Height:130mm
- Mast Inclination F/R:6,12deg
- Front Overhang:482mm
- Length to Face of Fork:2480mm
- Turning Radius:2320mm
- Min. Right Angle Aisle Width:1910mm
- Lift Speed:480mm,S
- Max. Grade Ability:20%
- Max. Drawbar Pull:14kn
- Self Weight:3720kg
- Certification:CE,ISO9001
- Transport Package:Nude Package, Container
- Specification:2680*1225*2120MM
- Trademark:Cruking
- Origin:China
- HS Code:8428909090
- Production Capacity:300units,Moth
Description
Overview
Specification 1 Model HH30Z-N2-D 2 Rated capacity kg 3000 3 Load center mm 500 4 Lift height mm 3000 5 Fork size L×W×T mm 1070×125×45 6 Mast inclination front/back(α°/β°) Deg 6/12 Size 7 Overall Dimension Length(to fork face) mm 2680 Overall Width mm 8 1225 Mast lowered height mm 9 2095 Height When Mast Lifting mm 10 4180 11 Safeguard Height mm 2120 12 Turning Radius min mm 2460 13 Front Overhang mm 490 14 Tread front/back mm 1000/970 15 Ground Clearance min(no load/full load) mast/frame mm 152/132158/138 16 Wheelbase mm 1700 17 Fork Spread min/max mm 300/1200 Performance 18 Speed Travel (Laden) km/h 20/18.5 Lifting (Laden) mm/s 19 480 20 Grade ability Laden % 20 21 Service Weight(include battery ) kg 4400 22 Tire Front 28×9-15-12PR rear 23 6.50-10-10PR Diesel Engine 24 XINCHAI 490BPG Rated Output Kw/rpm 37/2650 Rated Torque 25 N.m/rpm 148/1800 Displacement cc 26 2540 No.of Cylinder 27 4 Bore*Stroke 28 mm 90*100 29 Operating Pressure for Attachment Mpa 17.5
Product Description
Product Parameters
Detailed Photos
