3 Ton AC Electric Small Mini Wheeled Forklift
Shanghai Canmax Electronic & Mechanical Equipment Co., Ltd.- Cab Location：Not Adjustable
- Type：Electric Forklift
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Electric
- Load center：500mm
Base Info
- Lift height：3000~5000mm
- Condition：New
- Power Souce：AC Motor
- Overall Dimensions：3610X2175X1225 mm
- Weight：5080kg
- Rated Loading Capacity：3000kg
- Rated Capacity：3000kg
- Battery Capacity：80V,500ah
- Transport Package：Container ,Bulk Cargo Ship
- Specification：3610x2175x1225 mm
- Trademark：CANMAX
- Origin：Shanghai, China
- Production Capacity：100 Unit,Units Per Month
Description
1
Model
CPD30M
2
Power type
Battery
3
Rated capacity
kg
3000
4
Load center
mm
500
5
Lifting height
mm
3000
6
Free lifting height
mm
85
7
Fork size
mm
1070×130×40
8
Mast tilting angle
deg
6/12
9
Overall length
mm
3615
10
Overall width
mm
1230
11
Mast lowered height
mm
2020
12
Mast extended height
mm
4100
13
Overhead guard height
mm
2150
14
Min.turning radius
mm
2255
15
Speed
Travel speed
kg/h
14
16
Lifting height
mm/sec
250
17
Max. gradeability
%
10
18
Self weight
kg
4800
19
Electric control
Manufacturer
GE
20
Type
Separate excitation & two-control
