Hot 1t - 5t Manual Ltmg China Jacks Trucks Hydraulic Pallet Truck

Xiamen LTMG Machinery Co., Ltd.
  • After-sales Service：Free Parts
  • Warranty：1 Year
  • Cab Location：Not Adjustable
  • Type：Manual Pallet Truck
  • Power：Manual
  • Load Capacity：1T - 5T

Base Info

  • Model NO.：HPT20 FEP15 FEP20
  • Fuel：Manual
  • Load center：500mm
  • Condition：New
  • Capacity：2500kg
  • Fork Length：1150mm,1220mm
  • Min.Fork Height：85mm
  • Max.Fork Height：195mm
  • Wheels：PU
  • Self Weight：73-92kg
  • Qty/20 Feet Container：180,144PCS
  • Single Fork Width：160mm
  • Fork Overall Width：550,685mm
  • Fork Wheel-Single：80X93,74X93mm
  • Transport Package：Container
  • Specification：Could be designed by buyers
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427900000
  • Production Capacity：2000sets,Year

Description

Nylon wheel/ Polyurethane wheel /Ordinary rubber wheel,etcLoad wheel Sizemm70x8070X8070x8080x95Steer wheel Sizemm180x50180X50180x50180x50Min.fox heightmm80808080Max.fox heightmm200200200200Overall lengthmm1100120012001220Overall widthmm550685685550Overall heightmm1220122012201220Packing measurementmm2300x550x6502400X685X6502400x685x6502300x550x650Net weightkg58/ 65.563.5 / 7163.5 /7148 / 57.5

Product Features

1) Galvanizing fully-sealed pump,double tandem nylon wheels

2) Strengthen body and fork, 210 steering arc, small turing radius, fork lowering speed is controllable

3) Entry/exit roller, easy to entry into the pallet,equipment with over-load valve, 3 position hand control, durable, versatile and easy to use.

4) Heavy duty steel adjustable push rods/steel c-channel/handle base, Powder-coat paint finish

5) Rebuildable pump, Handle bolt designed for easy assembly and removal.

6) Options:PU/Rubber load wheels, single wheel,stainless steel and galvanized trucks available,various fork lengths and widths,backrests
