• Model NO.：HH30Z
• Lift height：>5000mm
• Condition：New
• Front Overhang：497mm
• Turning Radius：2460mm
• Rated Output：37kw
• Displacement：2540cc
• Transport Package：Standard Container
• Specification：2480x1150x2120mm
• Trademark：HUAHE
• Origin：China
• HS Code：84272090
• Production Capacity：500

GeneralsModelUnitHH30ZPower type DieselRated capacityKg3000Load centermm500DimensionsLift heightmm4500Free lift heightmm142Fork size (L× W× T)mm1070× 125× 45Mast inclination F/RDeg6° /12°Front overhangmm497Overall DimensionsLength to face of forkmm2680Overall widthmm1225Mast lowered heightmm2095Overhead guard heightmm2120Turning radiusmm2460Min. right angle aisle widthmm2105PerformanceTravel speedUnload I/IIKm/h9/20Full load I/IIKm/h8.8/19.5Lift speedmm/s400Max. grade ability%20Max. drawbar pullKn13.5Self weightKg4900Wheels & TiresTiresFront 28x9-15-12PRRear 6.50-10-10PRTreadFront Qmm1000Rear Smm970Wheelbasemm1700Min. ground clearance
(unload/full load)Mastmm152/110Framemm166/160Drive units & ControlBatteryV/Ah12/105EngineModel XINCHAI C490BPGRated outputKw/rpm37/2650Rated torqueN. m/rpm148/1800Displacementcc2540TransmissionType HydraulicShift Fwd/Rwd 1/1 Power shiftOperating pressureMpa17.5
