• Model NO.：CQD
• Fuel：Electric
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Operate Type：Standing Type
• Wheel Type：PU
• Min Rurning Radius：1680,1836mm
• Service Parking：Electromagnetic
• Drive Motor：4.5kw
• Lift Motor：6.3kw
• Battery Type：Lead Acid
• Battery V/Ah：48V,300ah
• Drive Motor Type：AC
• Transport Package：Pallet
• Specification：Electric forklift
• Trademark：CHEESON
• Origin：China
• HS Code：8427109000
• Production Capacity：5000sets,Year

Basic Info.

Model NO. CQD Fuel Electric Load center 500mm Lift height 3000~5000mm Condition New Operate Type Standing Type Wheel Type PU Min Rurning Radius 1680/1836mm Service Parking Electromagnetic Drive Motor 4.5kw Lift Motor 6.3kw Battery Type Lead Acid Battery V/Ah 48V/300ah Drive Motor Type AC Transport Package Pallet Specification Electric forklift Trademark CHEESON Origin China HS Code 8427109000 Production Capacity 5000sets/Year

Product Description

01 Curtis electric contro and controller multiple automatic protection system.

02 EPS steering energy consumption is reduced by 20%. It is conducive to accurate operation, reduces driver fatigue and greatly improves productivity.

03 The electric reach truck forklift is suitable for large tonnage and high lift cargo storage applications,applying to a variety of pallets,and has the characteristics of moving forward for overall gantry.Furthermore,it has small turning radius, ignoring the obstacles at the bottom of the shelf.So it is used in narrow channels.

04 During the lifting control lever is in the safe lowering position, the lowering speed of the fork automatically slows down .when it drops to 10cm from the ground, it can effectively preventing the goods from being damaged due to vibration. When the fork rises to the highest position, the buffer system reduces the gantry vibration and improves the operator's comfort.

05 The pedal power-off switch on the pedal controls the operation of the vehicle. Only after the pedal power-off switch is pressed, the vehicle can be operated. Otherwise, the vehicle will stop running. This design improves the safety performance of the whole vehicle.

06 48V high power battery with long endurance and battery life.
