• Model NO.：MK
• Lift height：>5000mm
• Condition：New
• Controller Brand：Curtis
• Certificate：Ce
• Power Type：Battery
• Operate Type：Seat
• Rated Capacity：5000kg
• Lift Motor Type：DC
• Drive Motor：AC Motor
• Brand：Mima
• Color：Red
• Lifting Height：6000mm
• Transport Package：Standard Packing
• Specification：ISO9001
• Trademark：MIMA
• Origin：Hefei
• HS Code：84271090
• Production Capacity：2000 Units,Year

         Model No. MK40MK45MK50StandardPower type BatteryBatteryBatteryOperate type SeatedSeatedSeatedRated capacityQ(kg)400045005000Load center C(mm)500500500WheelWheel type Solid rubber tireLoading wheel 18×7-821×8-921×8-9Driving wheel 23×10-12250-15250-15Wheel tread, drive side 108012251225Wheel tread, load side 99010251025Number of wheels. -front/rear (X=Drive wheel) 2X / 22X / 22X / 2DimensionMast tiltingα/β(º)6/116/116/11Lift heighth1(mm)300030003000Free lift heighth2(mm)///Mast closed heighth3(mm)210021802180Mat extended heighth4(mm)425640404040Overhead guard heighth6(mm)213022502250Mast ground clearanceh8(mm)90120120Overall length11(mm)377040604060Length to fork face12(mm)270029902990Wheelbasey(mm)180020002000Front overhangx(mm)484530530Overall widthb1/b2(mm)13301470/13501470/1350Fork dimensionsmm1070*125*501070*150*501070*150*50Fork outside widthb5(mm)250-1050320-1320320-1320Trurning radiusWa(mm)245026902690FunctionDriving speed, lode/unload km/h12/1312/1312/13Max. gradeability -load/unload%14/1515/1515/15Driving motor (S2-60min)kwAC14AC16.6AC16.6Lift motor type DCACACLift motor (S3-15%)kw101515Battery voltage/capacityV/AH80/45080/56080/630WeightBattery weightkg119513901690Service weightkg530068007100SteeringSteering type Full hydraulicParking brake model Hydraulic powerParking operation type Pedal
Why choose us
BANYITONG SCIENCE & TECHNOLOGY DEVELOPING CO., LTD.
       As the leading manufacturer of Chinese electric forklift and material handling equipment, we are specialized in designing and developing with all-around logistics handling solutions.
    Referring to 12 series and more than 50 kinds of products, MiMA can offer you with electric forklift, electric reach truck, pallet stacker, pallet truck, order picker, tow tractor, narrow aisle forklift, special forklift, AGV and other customized equipments, which can provide customers with logistics handling solutions from 500kg to 100,000kg. Due to serialization and standardization, all MiMA products are widely used in medicine, food, chemical, household electrical appliances, wool cotton textile, tobacco, electronics, machinery, furniture and many other industries.

Our workshop and warehouse







Many of our models are in stock, for more details please feel free to contact us.

Exhibition
