• Model NO.：CPD25
• Lift height：>5000mm
• Condition：New
• Load Center：500mm
• Self Weight：4300kg
• Front Overhang：420mm
• Min.Turning Radius：2050mm
• Transport Package：Standard Container
• Specification：2480x1150x2120mm
• Trademark：HUAHE
• Origin：Zhejiang, China
• HS Code：84272090
• Production Capacity：500

1Manufacturer FORKLIFT 2Model CPD20CPD25 3Power type Battery 4Rated capacitykg20002500General5Load center Qmm500500Dimensions6Lifting hight Hmm300030007Free lifting hight Zmm1508Fork size L×W×Tmm1070×122×409Mast tilting angle α/βdeg5°/10°5°/10°10Front overhang Emm42011Overall dimensionsLenght A+Bmm336012Widthmm116013Heihgt Xmm199514Max height Cmm396015Grand heightmm210016Min.turning radius Rmm205017Min.right angle stacking aisle width RASAmm2655+FPerformance18Full load/no loadTravel speedkm/h11/13 )19Lifting speedmm/sec230/330220/32020Max.grade ability%1521Self weightkg4100430022Max.tractionKN101123Climbing speedkm/h43.5 24TyreFront 7.00-12-12PR 25Rear 18×7-8-14PR 26TreadFront Smm970 27Rear Mmm950 28Wheel base Dmm1550 29Min height to floorMast Umm90/105Chassis30Frame Pmm95/110 Power & Control31BatteryVoltageV4832CapacityAh60033MotorDrive motor rated outputkw1034 Lifting motor rated outputkw1035Electric control CURTIS36PressureMpa17.5
