Compact Design Medium Level Order Picker Order Picking Truck

ZHEJIANG EP EQUIPMENT IMP. & EXP. CO., LTD.
  • Cab Location：Not Adjustable
  • Type：Order Picker
  • Power：AC Motor
  • Load Capacity：700kg
  • Fuel：Electric
  • Load center：600mm

Base Info

  • Model NO.：JX2-1
  • Lift height：1000mm
  • Condition：New
  • Wheelbase：1280mm
  • Turning Radius：1470mm
  • Travel Speed(H:0-370mm)：8 Km,H
  • Travel Speed(H:370-Max)：3.7 Km,H
  • Travel Speed,Backwards(H:0-370mm)：8 Km,H
  • Travel Speed,Backwards(H:370-Max)：3.7 Km,H
  • Drive Motor：2.5kw
  • Lift Motor：3kw
  • Battery：24V,360ah
  • Drive Type：AC
  • Steering Type：Electronic
  • Lift Speed：0.13,0.16
  • Lowering Speed：0.16,0.18 M,S
  • Max Gradeability：0 %
  • Service Brake：Electromagnetic
  • Transport Package：Export Standard
  • Specification：2520*800*2560mm
  • Trademark：EP
  • Origin：China
  • HS Code：8428909090
  • Production Capacity：3500units

Description

Steering typeElectronic10.7Sound pressure level  at the driver's  ear dB (A)75
Compact Design Medium Level Order Picker Order Picking Truck
