Ltmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery Charger

Xiamen LTMG Machinery Co., Ltd.
  • Warranty：1 Year or 2000 Working Hours Which Ever Comes Firs
  • Cab Location：Not Adjustable
  • Type：Electric Forklift
  • Power：AC Motor
  • Load Capacity：1T - 5T
  • Fuel：Electric

Base Info

  • Model NO.：FB35
  • Load center：500mm
  • Condition：New
  • Controller：AC
  • Fork Size：1070*125*45mm
  • Weight：4950kg
  • Wheel Base：1600mm
  • Max. Lifting Height：3000mm
  • Turning Radius(Outside)：2360mm
  • Tire：Pneumatic Tires,Solid Tires
  • Product Type：Electric Forklift
  • Transport Package：Container
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427109000
  • Production Capacity：800sets,Year

Description

ModelFB35Rated Capacitykg3500Load Centremm500Lift Heightmm3000Fork Size (L×W×T)mm1070×125×45Mast Tilt Angle F/R (α°/β°)Deg6/12Length to fork face of fork (Without fork)mm2615Overall Widthmm1230Mast Lowered Heightmm2110Mast Extended Height (With backrest)mm4180Overhead Guard Heightmm2250Turning Radius (outside)mm2350Front Overhang (Wheel center to fork face)mm485Tread (Front/Rear)mm1000/980Ground Clearance (Bottom of mast)mm140Wheelbasemm1700Fork Spread (Min./Max)mm250/1100Travel Speedkm/h14Lifting Speed (Full load)mm/s300Max. Gradeability%15Service Weightkg5100Front Tire×2 28×9-15-12PRRear Tire×2 18×7-8-14PRDriven Motorkw15Lift Motorkw12Battery StandardV/Ah80/550Controller Manufacturer CURTIS ACOperating Pressure for AttachmentMpa18

Ltmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery ChargerLtmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery ChargerLtmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery Charger
Ltmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery Charger
Ltmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery Charger
Ltmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery ChargerLtmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery ChargerLtmg 2ton 2.5ton 3ton Counterbalance Forklift 3.5 Ton Electric Forklift with Battery Charger
FAQ

1. What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3. How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, balance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6. Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
