Forklifts & Parts

Home > Product > Forklift

Ltmg 2 Ton Reach Truck 1.5 Ton Hydraulic Seated Electric Reach Forklift with 5 M Lifting Height

Xiamen LTMG Machinery Co., Ltd.
  • After-sales Service：Free Parts Within Warranty
  • Warranty：1 Year,2000 Working Hours
  • Cab Location：Not Adjustable
  • Type：Reach Forklift
  • Power：AC Motor
  • Load Capacity：1T - 5T

Base Info

  • Fuel：Electric
  • Load center：500mm
  • Lift height：3000~5000mm
  • Condition：New
  • Certificate：ISO CE
  • Color：Customize
  • Max.Lifting Height：4000mm
  • Fork Dimensions：1070mm*100mm*35mm
  • Battery：48V,300ah
  • Operator Type：Seated Type
  • Fork Size：1070mm*100mm*45mm
  • Power Unit：Battery
  • Rated Capacity：1500kg
  • Controller：Curtis
  • Transport Package：Container
  • Specification：2266mm*1098mm*2580mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427109000
  • Production Capacity：1000sets,Year

Description

The Speicification of 1.5ton electric reach forklift Model No.FRB15Rated Capacity (KG)1500Operate Typestand onMax. Lifting Height (MM)4000Min. Turning Radius (MM)1625Min. Stacking Aisle---mm (1000*1000 Pallet)2622Max Travel Speed km/h-laden/unladen7.5/8.5Load center MM500Fork Dimensions-L/W/T---mm---8.1070*100*35Max. Gradeability ---%10Lifting Speed (MM/S)-laden/unladen117/243Overall Length (MM)2266Overall Width (MM)1098Height-Overhead guard--mm2320Height---Mast Lowered(MM)2580Height-Mast Extended w/ Load-Backrest -mm4885Height--Free Lift --mm100Tilt Angle----Upward/Downward--deg.3/5Fork Spread Range (MM)220-662Reach Stroke560Min Ground Clearance--mm80Wheel TypePolyurethane Solid TyreDriving Wheel (MM)Φ343×108Balance Wheel (MM)Φ180×76Front Wheel (MM)Φ267×114Battery V/AH- "TONGBA"BRAND48V /300 AHService BrakeMECH.Parking BrakeMECH.Charger-Intelligent48V/40ADriving Motor (KW)5.5 (AC)Lifting Motor (KW)6.3


Ltmg 2 Ton Reach Truck 1.5 Ton Hydraulic Seated Electric Reach Forklift with 5 M Lifting Height
Ltmg 2 Ton Reach Truck 1.5 Ton Hydraulic Seated Electric Reach Forklift with 5 M Lifting HeightLtmg 2 Ton Reach Truck 1.5 Ton Hydraulic Seated Electric Reach Forklift with 5 M Lifting Height
Ltmg 2 Ton Reach Truck 1.5 Ton Hydraulic Seated Electric Reach Forklift with 5 M Lifting HeightFAQ

1.What's the Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System. All of our products with CE certificate.

 2.Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements. However, All the customizing and
refit should be implemented safely and scientifically. The colors can be painted as client's need.

3.How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy
for each model.

4.Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

 5.What's the payment terms do you accept?
On T/T term 30% down payment is required in advance,and 70% balance shall be settled before shipment.

 6.What logistics ways we can work for shipment ?
We can ship construction machinery by various transportation tools.
1.For 90% of our shipment,we will go by sea,to all main continents such as South America,Middle East,
Africa,Oceania and Europe etc,either by container or Bulk shipment.
2.For neighborhood countries of China,such as Russia,Mongolia, Kazakhstan,Uzbekistan etc., we can
ship trucks by railway.
3.For light spare parts in urgent demand,we can ship it by international courier service,such as DHL,TNT,
UPS,or Fedex.

7.Delivery time:
Standard configuration products are always in stock. The production period of Customizing products is 30 days.
