• Lift height：3000~5000mm
• Condition：New
• Engine：Chinese, Japanese,Cummis
• Color：Customerized
• OEM：Support
• Certification：Ce, ISO9001, Co
• Fork Length：Customerized
• Tyres：Pneumatic Tyre, Solid Tyre
• Wheel Drive：4WD
• Cabin：Free
• Forklift Attachment：Support
• Optional：Side Shift, Three Stage Mast, etc
• Transport Package：Standard Export Package
• Specification：diesel forklift
• Trademark：GP
• Origin：China
• HS Code：8427201000
• Production Capacity：50000 Per Year

Basic Info.

Lift height 3000~5000mm Condition New Engine Chinese, Japanese,Cummis Color Customerized OEM Support Certification Ce, ISO9001, Co Fork Length Customerized Tyres Pneumatic Tyre, Solid Tyre Wheel Drive 4WD Cabin Free Forklift Attachment Support Optional Side Shift, Three Stage Mast, etc Transport Package Standard Export Package Specification diesel forklift Trademark GP Origin China HS Code 8427201000 Production Capacity 50000 Per Year

Product Description

Data sheet:

Model#	CPCY 30	CPCY 35	CPCY 50	CPCY 70	CPCY 100	W 35
Rated load (kg)	3000	3500	5000	7000	10000	3500
Lifting height (mm)	3000	3000	3000	3000	3000	3000
Load centre	500	500	600	600	600	500
Without fork  Length (mm)	3515	3655	4420	4420	5425	3330
Width (mm)	1700	1700	2185	2200	2620	1700
Max. height  (mm)	2720	2150	3100	3100	3400	2150
Mast Tilt Angle Front/Rear	6/12	6/12	6/12	6/12	6/12	6/12
Wheelbase (mm)	2080	2080	2185	2185	2745	1840
Tread	1170	1170	1575	1575	1850	1170
Tyres	12-16.5 (12PR)	12-16.5 (12PR)	16/70-20 (14PR)	F: 11.00-20 (18PR) R: 16/70-20 (14PR)	F: 14.00-24 (18PR) R: 17.5-25 (14PR)	12-16.5 (12PR)
Self weight (kg)	4340	4230	7900	9160	14500	4550
Battery Voltage/Capacity	24 V ( 80ahx2 )	24 V ( 80ahx2 )	24 V ( 80ahx2 )	24 V ( 100ahx2 )	24 V ( 80ahx2 )	24 V ( 60ahx2 )
Standard Engine brand	XINCHAI	XINCHAI	FAW	FAW	FAW	XINCHAI
Standard engine model	C490 BPG	C490 BPG	4DX21-72	4DX22-96	CA6110	C490 BPG
Standard engine power (kw)	40	40	57	70	92	40
Transmission	Automatic  2F/2R	Automatic  2F/2R	Automatic  2F/2R	Automatic  2F/2R	Automatic  4F/2R	Automatic  2F/2R
Unload Max speed (km/H)	28	28	25	25	33	28
Max. Gradeability (Laden) %	22	22	22	22	20	22
Fork size L×W×T (mm)	1220*125*45	1220*125*50	1520*150*55	1520*150*65	1820*175*80	1220*125*45
Min. ground clearance(drive steer axle)(mm)	260	260	300	300	390	260
Turning radius (mm)	4500	4760	5290	5290	5500	4900


GP forklift product advantages and characteristics
1,Japan TCM forklift system technology, a leading international level.
2,the forklift with the principle of human engineering, fully humanized design.
3, the entire forklift used Japanese imports of seal, bearing and electrical components, further to ensure the reliability of the forklift
4,internal combustion forklift using  high-power engine of Euro III emission standards, not only guarantee the forklift power and ensures the environmental.
5, battery forklift  using USA or Italy assembly  electronic control and imports of electrical components, and fully guarantee the stability of forklift truck.
6,with strict accordance of ISO9000 and CE standards for product development and production, ensure quality of forklift.
7,all sold products enjoy a high quality after sale service, ensure the spare parts supply timely, quality and continuity, to solve customer any worry from the later period.
