• Model NO.：CPD 25
• Condition：New
• Rated Loading Capacity：2500kg
• Max. Lifting Height：4040mm
• Min. Lifting Height：110mm
• Fork Length：1070mm
• Fork Width：122mm
• Overall Dimensions：3380*1160*2130
• Certification：CE ISO9001
• Color：Orange
• Weight：4300kg .
• Transport Package：20gp: 4set , 40hq: 8sets
• Specification：CE
• Trademark：WELVO
• Origin：Shandong, China
• HS Code：8427209000
• Production Capacity：3000 Sets One Year

MODEL
CPD25C
Load capacity
2500 kg
Load center
500 mm
Power type
Battery
Max. lifting speeds(with load)
230 mm/s
Max. driving speeds(with/without load)
12/14 km/h
Max towering (with load)
10 kn
Grade ability(with load)
15%
Lifting height
3000 mm
Free lift
60 mm
Tilting angles(forward-backward)
6 ° /12 °
Min. turning radius
2250 mm
Min. Right angle aisle width
2100 mm
Min. under-clearance
110 mm
Dimensions
Overall length(including fork)
3380 mm
Overall width
1160 mm
Overall height(mast lowered)
2130 mm
Overall height(mast extended)
4040 mm
Overall height to overhead guard
2130 mm
Fork width
122 mm
Fork thickness
40 mm
Fork length
1070 mm
Fork overhang
451 mm
Wheel base
1550 mm
Tread
Front tread
970 mm
Rear tread
950 mm
Tire
Front tire
7.00-12
Rear tire
18 ×7-8
Total weight
4300 kg
Motor
Traction motor
XQ-8
Lifting motor
XQD-10-3S
Battery
Battery type
D-700
Battery voltage/capacity
48V/700Ah
