1.5 Ton 2 Ton 2.5 Ton Stand up Sit Down Electric Reach Truck Forklift for Narrow Aisle Warehouse
Xiamen LTMG Machinery Co., Ltd.- After-sales Service：Free Parts Within Warranty
- Warranty：1 Year,2000 Working Hours
- Cab Location：Not Adjustable
- Type：Reach Forklift
- Power：AC Motor
- Load Capacity：1T - 5T
Base Info
- Model NO.：FRB15
- Fuel：Electric
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Certificate：ISO CE
- Color：Customize
- Max.Lifting Height：4000mm
- Fork Dimensions：1070mm*100mm*35mm
- Battery：48V,300ah
- Operator Type：Seated Type
- Fork Size：1070mm*100mm*45mm
- Power Unit：Battery
- Rated Capacity：1500kg
- Controller：Curtis
- Transport Package：Container
- Specification：2266mm*1098mm*2580mm
- Trademark：LTMG
- Origin：China
- HS Code：8427109000
- Production Capacity：1000sets,Year
Description
The Speicification of 1.5ton electric reach forklift Model No. FRB15 Rated Capacity (KG) 1500 Operate Type stand on Max. Lifting Height (MM) 4000 Min. Turning Radius (MM) 1625 Min. Stacking Aisle---mm (1000*1000 Pallet) 2622 Max Travel Speed km/h-laden/unladen 7.5/8.5 Load center MM 500 Fork Dimensions-L/W/T---mm---8. 1070*100*35 Max. Gradeability ---% 10 Lifting Speed (MM/S)-laden/unladen 117/243 Overall Length (MM) 2266 Overall Width (MM) 1098 Height-Overhead guard--mm 2320 Height---Mast Lowered(MM) 2580 Height-Mast Extended w/ Load-Backrest -mm 4885 Height--Free Lift --mm 100 Tilt Angle----Upward/Downward--deg. 3/5 Fork Spread Range (MM) 220-662 Reach Stroke 560 Min Ground Clearance--mm 80 Wheel Type Polyurethane Solid Tyre Driving Wheel (MM) Φ343×108 Balance Wheel (MM) Φ180×76 Front Wheel (MM) Φ267×114 Battery V/AH- "TONGBA"BRAND 48V /300 AH Service Brake MECH. Parking Brake MECH. Charger-Intelligent 48V/40A Driving Motor (KW) 5.5 (AC) Lifting Motor (KW) 6.3
