2.0ton Capacity Electric Side Loading Forklift
Shanghai Hytger Industry & Trade Co., Ltd.- Type：Powered Pallet Truck
- Power：AC Motor
- Load Capacity：1T - 5T
- Fuel：Diesel
- Load center：500mm
- Lift height：3000~5000mm
Base Info
- Model NO.：FDD20
- Condition：New
- Name：2.0ton Electric Side Load Forklift
- Capacity：2000kg
- Lifting Height：3000mm
- Lift Speed Laden：250mm,S
- Minimum Turning Radius：4300mm
- Platform Height：990mm
- Platform Width：1150mm
- Fork Length：1150mm
- Overall Dimension：4450*2030*2700mm
- Weight：7800kg
- Transport Package：Standard Exporting Packing
- Specification：CE, SGS, ISO
- Trademark：SHYTGER
- Origin：Shanghai, China
- HS Code：84272090
- Production Capacity：3000units,Year
Description
ModelFDD20 Carrying capacity (load centre 600mm) 2000kg lift Height & Max.height 3500/6000mm Fork free lift height 300mm Max.lift speed 250m/s Max.traveling speed 15km/h Fork tilt anger (front/rear) 5°/3° Min.turning radius 4300mm Gradeability (laden) 15% Min.ground clearance (laden) 170mm Overall dimension Length 4450mm Width 2030mm Height Fork in the lowest position 2700m Fork in the highest position 4660mm Wheel base 2460mm wheel tread 160mm Platform height (laden) 920m Platform width 1150mm Fork length 1150mm Max.fork spacing 940mm Tire size 8.25-15-14PR Weight (unladen) 6800kg Volts AH battery 80V/700Ah Traction motor 16.6kw Pump motor 13.5kw Control system A-Impulse(CURTIS)
FAQ:1.Why choose SHytger?For it's good quality,a reasonable price,and high-class service. 2.What's your advantage? -We have been specialized in forklift market over 10 years. -Strict quality control in every detail.We supply spare parts to almost all China forklift market. -Popular in many countries,eg: USA ,Pakistan ,Malaysia, Austrilia,and so on. -Company spirits:Your satisfaction,our happiness. 3.How many forklift colors can you supply? Silver, orange, yellow .As you request.
