• Model NO.：FG60
• Fuel：LPG
• Load center：600mm
• Lift height：3000mm
• Condition：New
• Fork Size：1220mm*150mm*60mm
• Weight：9150kg
• Engine：Psi 4.3 EPA
• Wheel Base：2250mm
• Color：Decided by Buyer
• Certificate：EPA ISO CE
• Rated Power：56kw,2200rpm
• Max.Lifting Height：3000mm
• Name：Wholesale Hydraulic Forklift 6 Ton LPG Forklift Wi
• Tire：Pneumatic
• Transport Package：Container
• Specification：3450mm*2010mm*2550mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

General1Model FG602Power type LPG3Rated Capacitykg60004Load centremm600Characteristic&Dimension5Lift Heightmm30006Fork SizeL×W×T   mm1220×150×607Mast title AngleF/RDeg6°/12°8Front Overhang (Wheel center to fork face)mm5909Ground clearance (Bottom of mast)mm20010Overall DimensionLength to face of fork (without fork)mm345011Overall widthmm201012Mast Lowered Heightmm255013Mast Extended Height (with backrest)mm438014Overhead Guard Heightmm247015Turning Radius (outside)mm325016Min. intersecting aislemm2960Performance17SpeedTravel(no load)km/h3018Lifting(full load)mm/s50019Max Gradeability%20Chassis 20TireFront 8.25-15-14 PR21Rear 8.25-15-14 PR22Wheelbasemm225023Service Weightkg9150Power&Transmission24BatteryVoltage/Capacity                                      V/Ah(12V/80AH) × 225EngineModel PSI 4.326Manufacture PSI27Rated output/r.p.m.kwt/r.p.m56/220028Rated torque/r.p.m.N·mt/r.p.m240/75029No.of Cylinder 630Bore×Strokemm101.6×88.3931Displacementcc430032 Fuel Tank CapacityL14033TransmissionType Hydraulic34StageFWD/RVS 2/235Operating pressure for attachmentMpa19
