1500kg 2000kg PU Manual Stacker
Ningbo Cholift Forklift Co., Ltd.- Warranty:1 Year
- Cab Location:Fork Lift
- Type:Manual Stacker
- Power:Manual
- Load Capacity:1000kg
- Fuel:Manual
Base Info
- Load center:500mm
- Lift height:1600-3000mm
- Condition:New
- Fork Width:100mm
- Overall Dimensions:1400*741*2080mm
- Lifting Height:2500mm
- Rated Loading Capacity:1000kg
- Power Souce:Hydraulic Oil
- Manufacturer:Ningbo Cholift Forklift Co., Ltd.
- Min. Lifting Height:2080mm
- Mast:Single Mast
- After-Sales Service Provided:Overseas Third-Party Support Available
- Max. Lifting Height:2500mm
- Wheel Material:Nylon
- Certification:CE TUV ISO
- Fork Type:Adjustable Fork
- Fork Length:900mm, 900mm
- Transport Package:Plywood Pallets for Manual Pallet Stacker
- Specification:1500kg
- Trademark:CHOLIFT
- Origin:Ningbo, China
- HS Code:84279000
- Production Capacity:1000 Pieces Per Day Hydraulic Hand Fork Lift
Description
Product DescriptionTechnical parameterModel SDA10 SDA15 SDA20 Load capacity/rated load Q(kg) 1000 1500 2000 Load centre distance c (mm) 500 400 400 Tyre size,front mm Φ80*70 Φ80*70 Φ80*70 Tyre size rear mm Φ180*50 Φ180*50 Φ180*50 Lifting height H (mm) 1600/2500/3000 1600/2500/3000 1600 Fork lowered height h (mm) 90 90 90 Most lowered height F (mm) 2080/1830/2080 2080/1830/2080 2080 Groung clearance X (mm) 30 30 30 Turning radius R (mm) 1200 1200 1200
About us
1.Our company has a professional team with 23 years' rich experience.
2.We have get several patents of pallet trucks and electric products.
3.We keep our 3 controls :quality control,cost control and service control.
4.Our company has passed ISO9001 and most of our products get CE and GS certification of TUV AUSTRIA.
