• Model NO.：FD50
• Condition：New
• Fork Size：1220mm*150mm*60mm
• Weight：7830kg
• Engine：Mitsubishi
• Wheelbase：2000mm
• Color：Decided by Buyer
• Rated Power：52kw,2300rpm
• Overall Length(Without Fork)：3183mm
• Free Lift：205mm
• Front Face of Fork to Front Axle：615mm
• Transport Package：Container
• Specification：3183mm*1485mm*2390mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：1000sets,Year

Model


FD50
Load capacity

kg
5000
Load center

mm
600
Power unit


Diesel
Operator type


Driver/seat
Tire type


Pnenumatic
Wheel
Front/rear

2/2
Max. lifting height

mm
3000
Free lift

mm
140
Fork size
L*W*T
mm
1220*150*60
Tilt range
Mast forward/backward
deg
6/12
Overall length(without fork)

mm
3183
Total width

mm
1485
Mast height (fork lowering)

mm
2390
Overall height fork raised
With backrest
mm
4295
Height to head guard

mm
2270
Turning raduis(outside)

mm
2865
Front face of fork to front axle

mm
560
Min. right angle stacking aisle
pallet size :1100×1100 add clearence
mm
4670
Speed
Max Travelling          full/no load
km/h
18/19
Lifting                         full/no load
mm/s
380/430
Lowering                    full/no load
mm/s
380/340
Max.drawbar pull
full/no load
kg
4500/2000
Gradeability at 1.6km/h
full load
%
25
Truck weight

kg
7830
Weight  distribution
Full  load front/rear
kg
10280/1790
No  load  front/rear
kg
3330/4500
Tires
Number
front/rear
2/2
Model
front axle
300-15-18PR
rear axle
7.00-12-12PR
Wheelbase

mm
2000
Tread
Front/rear
mm
1180/1190
Ground clearence
At lowest point(mast)
mm
100
Frame
mm
240
Brake
Service  brake

power brake
Parking brake

Mechanical-hand lever
Battery
Voltage/capacity
V/AH
2-12/80
Engine
Model

MITSUBISHI S6S
Rated power
kw/rpm
52/2300
Rated torque
N-m/rpm
248/1700
Number of cylinders

6
Displacement
L
4.996
Fuel tank capacity

L
80
Transmission
shift stage(front/rear-type)

2-1 power shift T/M
Operating pressure
Hydraulic system pressure
kg/cm²
200
