Weichai Engine Shantui Diesel Sfd30 3 Ton Forklift for Sale
Shandong Shantui Construction Machinery Import & Export Co., Ltd.- After-sales Service：Yes
- Warranty：24 Months
- Cab Location：Not Adjustable
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：1T - 5T
Base Info
- Model NO.：SFD30
- Fuel：Diesel
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Engine：Weichai Wp3.2
- Transmission：Kion
- Main Pump：Kion
- Main Valve：Kion
- Transport Package：by Container
- Specification：2.81*1.3*2.1m
- Trademark：SHANTUI
- Origin：China
- Production Capacity：10000sets,Year
Description
Basic Info.
Model NO. SFD30 Fuel Diesel Load center 500mm Lift height 3000~5000mm Condition New Engine Weichai Wp3.2 Transmission Kion Main Pump Kion Main Valve Kion Transport Package by Container Specification 2.81*1.3*2.1m Trademark SHANTUI Origin China Production Capacity 10000sets/YearProduct Description
| ITEMS DESCRIPTION | UNITS | DESIGN VALUE |
| Model designation | SFD30 | |
| Power type: Electric-Diesel-Petrol-LPG-Network Power (Electric) | diesel | |
| Operation Type: Hand-stand on-Driver seated | Driver seated | |
| Load Capacity | Q(Kg) | 3000 |
| Load Barycenter Distance | C(mm) | 500 |
| Axle centre to fork face | X(mm) | 484 |
| Wheel Base | Y(mm) | 1700 |
| Service Weight | kg | 4260 |
| Axle loading, laden front/rear | kg | 6460/800 |
| Axle loading, unladen front/rear | kg | 1700/2580 |
| Tyres: SE-Super elastic PN-Pneumatic | PN | |
| Front Tyres Size | 28 x 9-15-14PR | |
| Rear Tyres Size | 6.50-10-10PR | |
| Wheels,number front/rear(x=driven wheels) | 2×/2 | |
| Front Track Width | b10 (mm) | 1000 |
| Rear Track Width | b11 (mm) | 970 |
| Mast lift,forward/backward | ( /ad) Gr | 6°/12° |
| Mast Minimum Overall Height | h1(mm) | 2080 |
| Free lift | h2(mm) | 145 |
| Lift height | h3(mm) | 3000 |
| Mast Maximum Overall Height | h4(mm) | 4273 |
| Overhead Guard Height | h6(mm) | 2108 |
| Seat Height | h7(mm) | 1070 |
| Drawbar Height | h10(mm) | 300 |
| Overall Length | L1(mm) | 3780 |
| Lenght to Face of Forks | L2(mm) | 2710 |
| Overall Width | b1(mm) | 1225 |
| Fork Arms Dimensions | s/e/l(mm) | 45/125/1070 |
| Fork Carriage in Compliance with ISO 2328 Class/Form A,B | A | |
| Fork Carriage Width | b3(mm) | 1100 |
| Ground Clearance below Mast(laden) | m1(mm) | 135 |
| Ground Clearance Centre of Wheelbase(laden) | m2(mm) | 140 |
| Working aisle width with pallet 1000 x 1200 crossways**** | Ast(mm) | 4144 |
| Working aisle width with pallet 800 x 1200 lengthways**** | Ast(mm) | 4344 |
| Turning Radius | Wa(mm) | 2460 |
| Turning Point Minimum Distance from the Truck Center Line | b13(mm) | 810 |
| Drive Speed laden/unladen | km/h | 20/20.5 |
| Lifting Speed laden/unladen | mm/s | 480/540 |
| Lowering Speed laden/unladen | mm/s | 440/455 |
| Drawbar Pull Tractive E ort (at 2km/h) with/without load | KN | 16.2/14 |
| Gradeability (at 2km/h) laden/unladen | % | 20 |
| Service Brake | Mechanical/hydraulic | |
| Engine Manufacturer/Engine Type | WEICHAI WP3.2 | |
| Emission Standard | CHINA STAGE III | |
| Engine Power in compliance with ISO 1585 | kW | 36.8 |
| Rated Number of Revolutions | r/min | 2500 |
| Cylinder Number/Displacement | cm | 4/3170 |
| Fuel Consumption in Compliance With VDI-Cycl | ||
| On-board voltage | V | 12 |
| Drive Control Type | Mechanical/Hydraulic torque converter | |
| Service Pressure f or Attachments | ||
| Oil Flow rate f or (max.available) | ||
| Volume fuel tank | L/Kg | 52/45 |
| Noise at Operator's Ear | ||
| Drawbar,model/Type DIN | Pin |
