• Model NO.：T50P
• Lift height：3000-6000
• Condition：New
• Battery：24V,90ah
• Fork Size：1220*150*50
• Transport Package：Standard Export Packing
• Specification：3541*2067*2545MM
• Trademark：Royal
• Origin：China
• HS Code：8427209000
• Production Capacity：500PCS,Year

Basic Info.

Model NO. T50P Lift height 3000-6000 Condition New Battery 24V/90ah Fork Size 1220*150*50 Transport Package Standard Export Packing Specification 3541*2067*2545MM Trademark Royal Origin China HS Code 8427209000 Production Capacity 500PCS/Year

Product Description

Manufacturer			RY
	MODEL		T50P
General	Power Type		DIESEL
	engine		/
	Rated Load Capacity	kg	5000
	Load Centre	mm	600
Characteristic & Dimension	Rated Lift Height	mm	3000
	Free Lift Height	mm	/
	Mast Tilt Angle (F/R, α°/β°)	Deg	15º/15º
	Mast Lowered Height	mm	2565
	Mast Extended Height (With Backrest)	mm	4016
	Overhead Guard Height	mm	2545
	Ground Clearance (Bottom of Mast)	mm	320
	Length to Face of Fork (Without Fork)	mm	2997
	Overall Width	mm	2067
	Fork Size (L×W×T)	mm	1220X150X50
	Fork Overhang (Wheel Center to Fork Face)	mm	732
	Rear Overhang	mm	740
	Turning Radius (Outside)	mm	3516
	Min.Right Angle Stacking Aisle Width (Add Load Length and Clearance)	mm	/
Performance	Travel Speed (No Load)	km/h	22
	Travel Speed (Full Load)	km/h	/
	Lifting Speed (Full Load)	mm/s	570/500
	Lowering Speed  (Full Load)	mm/s	500
	Max.Drawbar Pull (Full Load)	KN	17
	Max.Gradeability (Full Load)	%	30/32
	Service Brake (Operation/Control)		Foot/Powershift
	Parking Brake (Operation/Control)		Hand/Mechanical
