• Model NO.：Pb05-Ra2
• Lift height：3000~5000mm
• Condition：New
• Rated Capacity on Standing Platform：136kg
• Rated Capacity on Behind Platform：137kg
• Rated Capacity on Front Platform：227kg
• Transport Package：Container,Roro,Bulk
• Specification：920*122*40 mm
• Trademark：Zoomlion
• Origin：China
• HS Code：8427209000
• Production Capacity：500unit,Month

SpecificationsUnitPB05-RA2(2200)PB05-RA2(3200)PB05-RA2(3600)PB05-RA2(4100)CharacteristicsDrive unit                                           ElectricalElectricalElectricalElectricalOperator type Stand onStand onStand onStand onrated capacity  on front platformKg227227227Δ227rated capacity  on behind  platformKg137137137137rated capacity  on standing platformKg136136136136Wheelbasemm1150115011501150WeightService weight (include battery)kg1090116012301340Axle loading, laden driving side/loading sidekg650/940680/980710/1020740/1100Axle loading, unladen  driving side/loading sidekg475/615490/670500/730520/820Types,ChassisTyre type, Driving wheels/Loading wheels PU/RubberPU/RubberPU/RubberPU/RubberTyre size, driving wheels(Diameter×Width)mmΦ230*75Φ230*75Φ230*75Φ230*75Tyre size, loading wheels(Diameter×Width)mmΦ204*76Φ204*76Φ204*76Φ204*76Tyre size, caster wheels(diameter×width)mmΦ102*61.5Φ102*61.5Φ102*61.5Φ102*61.5Wheels, number driving,caster/loading (x=drive wheels)mm1,2/21,2/21,2/21,2/2DimensionsHeight, mast loweredmm1590159016702090Seat height/standing height)mm250250250250Stand height, elevatedmm2200320036004100Overall lengthmm1500150015001500Overall widthmm800800800800Ground clearance, center of wheelbasemm50505050front cargo platform widthmm800×520800×520800×520800×520initial height of front  cargo platformmm1082108210821082Control handle heightmm1010101010101010behind platform widthmm346×660346×660346×660346×660Overall length platform launchmm1795179517951795The channel widthmm1750175017501750Turning radiusmm1385138513851385Performance datadrive speed, laden/unladenkm/ h5.55.55.55.5drive speed, laden/unladenkm/ h3.73.73.73.7drive speed, laden/unladenkm/ h2.52.52.52.5drive speed, laden/unladenkm/ h1111Lifting speed, laden/ unladenm/ s0.17/0.210.17/0.210.17/0.210.17/0.21Lowering speed, laden/ unladen)m/ s0.35/0.260.35/0.260.35/0.260.35/0.26Max. gradeability, laden/unladen%0000Service brake type ElectromagneticElectromagneticElectromagneticElectromagneticElectric-engineDrive motor rating S2 60 minkW1.51.51.51.5Lift motor rating at S3 15%kW2.22.22.22.2The maximum allowed size batterymm200x740x670200x740x670200x740x670200x740x670Battery voltage/nominal capacity K5V/ Ah24V/224AH K2024V/224AH K20 24V/224AH K2024V/224AH K20Battery weightkg163163163163Electric-engineType of drive unit ACACACACSteering type EletricalEletricalEletricalEletricalSound pressure level at the driver's eardB (A)74747474
