Haiqin Brand 3.0ton Electric Forklift (HQEF30) with CE Approvel
Weifang Haiqin Top Machinery Co., Ltd.- After-sales Service：24 Hours Every Day of Technology and Parts Service
- Warranty：12 Months
- Cab Location：Adjustable
- Type：Electric Forklift
- Power：DC Motor
- Load Capacity：1T - 5T
Base Info
- Model NO.：HQEF30
- Fuel：Electric
- Load center：500mm
- Lift height：3000~5000mm
- Condition：New
- Rated Loading Capacity：3000kg
- Max. Lifting Height：3000mm
- Power Souce：DC Motor
- Transport Package：by Container
- Specification：CE, ISO, SGS
- Trademark：Haiqin
- Origin：Shandong, China
- HS Code：84271090
- Production Capacity：9000 Units , Year
Description
Main information Model HQEF30 Power type Battery Rated load KG 3000 Load center distance mm 500 Driving type Seat Measurement 1 Length With fork L1 mm 3630 Without fork L2 2560 2 Whole Width B 1220 Height Height no lifting frame H1 2080 3 Top frame height H2 2215 Max Height working H3 4185 4 Distance from seat to top light L3 1060 5 Wheel base L4 1680 6 Front overhang Y 490 7 Back overhang L5 425 8 Front wheel tread R 1000 9 Back wheel tread P 980 10 Min Floor clearance F 145 11 Max lifting height H 3000 12 Free lifting height H4 160 13 Fork changing S 1060/250 14 Min Turning radius WA 2200 15 Min driiving width RA 4100 Performance 16 Frame angle a/β (°) 6°/12° 17 Max lifting speed without goods mm/s 425 18 Max lifting speed with full goods 260 19 Max speed without goods Km/h 14 20 Max speed with full goods 12.5 21 Max climbing angle % ≤15 Weight 23 Whole weight Kg 5600 Wheels and tire 26 Driving Wheel 2x/2 27 Type model Solid Tyre 28 Front Tyre 28X9-15 29 Rear Tyre 18x7-8 30 Hand Brake Hydraulic Pedal 31 Brake type M-Hand Battery and motor 32 Battery Volt/ capacity V/Ah 80/500 33 Driving motor power Kw AC16.6 34 Pump power AC12
