• Model NO.：LG25B
• Fuel：Electric
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Fork Length：1070mm
• Fork Width：125mm
• Free Lifting Height：165mm
• Max.Traveling Speed：20km,H
• Min.Turning Radius：2460mm
• Max. Lifting Height：3000mm
• Max.Traveling Speed(Km/H)：20
• Masttiltangle(Deg)：6,12
• Certification：CE,ISO9001
• Transport Package：Nude Package, Container
• Specification：1070*120*40mm
• Trademark：Cruking
• Origin：China
• HS Code：8428909090
• Production Capacity：300units,Moth

Overview

Product Description

Product Parameters

ModelLG25BPowertypeBatteryRatedcapacity(Kg)2500JLoadcentre(mm)500h1STDMax.liftingheight(mm)3000h3Freeliftingheight(mm)160L3*W*TForksize(mm)1070×120×40Masttiltangle(deg)6/12XFrontoverhang(mm)460R1Min.turningradius(mm)2150Min.width for pallets 1,000×1,200 crossways (L×W)(mm)3810Min.width for pallets 800×1,200 lengthways (L×W)(mm)4010Max.travelingspeed(km/h)12Max.liftingspeed(mm/s)(load/unload)260/420Max.gradient(%)12/15STD Dead weight(kg)4150S/PTread(front/rear)(mm)950/930L2Axledistance(mm)1500Min.groundclearance, m1Frame(mm)173TireFront7.00-12-12PRRear18×7-8-14PRMotorTravel(AC)(kW)11Lift(AC)(kW)12Battery(V/Ah)48/600Workingpressure(Mpa)17.5
