• Model NO.：FG40
• Lift height：3000mm
• Condition：New
• Engine Model：Gq-4y
• Rated Power：57kw,2800rpm
• No.of Cylinder：4
• Wheelbase：1900mm
• Fork Size：1070mm*130mm*50mm
• Length with Fork：2895mm
• Overall Width：1410mm
• Mast Tilt Angle：6,12
• Fuel Tank：60L
• Min. Turning Radius(Outside)：2700mm
• Transport Package：Container
• Specification：2895mm*4140mm*2150mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

ModelUnit FG40Power type Gasoline/Liquefied gas/Natural gasRated capacity kg4000Load centermm500Operator type Drive in seatMax. lift height of mast with Load-backrest mm4275Max.lift  height of fork(standard)mm3000Height of mast (standard)mm2150Free lift height(standard)mm150Height of Load-backrestmm1240Front wheel overheadmm2105Length with forkmm2895Front overhangmm500Rear overhangmm495Wheel basemm1900The height of traction pinmm330Min. ground clearancemm130Overall widthmm1410The distance between forksmm1290/260Tread(front /rear)mm1160/1065Min. Turning radius(outside)mm2700Min. Turning radius(inside)mm230Min. Intersecting aislemm2685Mast tilt angledeg6° / 12°Fork sizemm1070X130X50
SpeedsMax.Drive speeds(with/without load)km/h18/19Lifting speeds (with load)mm/s350/380Lowering speeds(with /without full load)mm/s350/400Max. tractive forceKN20/18Max.grade ability (with/without full load)%15/18Total weightkg4270Weight Distribution full load (front/ rear)kg8380/930Weight Distribution zero load(front / rear)kg2120/3190Quantity of wheels  2X / 2Type of tyres Penumatic tiresTiresFront  250-15-16PRRear 6.00-10-10PRDriving Brake hydraumatic pedalParking Brake Mechanical manual BatteryV/AH12/80Engine (standard)Model GQ-4YRated outputkw/rpm57/2800Rated torqueN.m/rpm198/1800No.of cylinder 4-91X86DisplacementL2.237Fuel tank capacityL60Number of speeds for transmission 1-1 Power shift transmission
/ 2-2 Hand shift transmission
Product Features

1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.

2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.

3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.

4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.

5.Environmental:
Middle muffler, more environmental.

6.High technology:
Maintenance free radiators adopt Germany technology.
