High Load 5ton Autonomous Agv Forklift Price
Shandong TOROS Machinery Co., Ltd.- Warranty：1 Year
- Cab Location：Adjustable
Base Info
- Type：Diesel Forklift
- Power：Diesel Engine
- Load Capacity：3t-8t
- Fuel：Diesel
- Load center：>500mm
- Lift height：3000~6000mm
- Condition：New
- Front Ground Clearance：250-380mm
- Platform Ground Clearance：300-350mm
- Fork Length：1220-1520mm
- Turning Radius：3500-4500mm
- Gantry Width：160-180mm
- Engine Power：40-76kw
- Rated Lifting Height：3000-6000mm
- Drive Type：4-Wheel Drive
- Frame：Hinged Thick 3-3.5mm
- Gradeability：38 Degree
- Transport Package：Standard Packaging
- Specification：Multiple models optional
- Trademark：TOROS
- Origin：China-Shandong
- HS Code：8430419000
- Production Capacity：500,Month
- Package size per unit product：200.00cm * 150.00cm * 200.00cm
- Gross weight per unit product：1000.000kg
Description
Model
VT-3000
VT-3500S
VT-4000
VT-5000
Dimensions
4200*1800*2700mm
4200*1800*2700mm
4400*1850*2800mm
4400*1900*2900mm
Engine model
HUADONG 4DBY4(490)
YUNNEI YN27(490)
HUADONG 4DHZY4(4102 Turbocharged)
YUNNEI YN38GBZ(4102 Turbocharged)
Fork length
1220mm
1220mm
1520mm
1520mm
Rated lift weight
3000kg
3500kg
4000kg
5000kg
Turning radius
3500mm
3500mm
4500mm
4500mm
Platform ground clearance
300mm
300mm
350mm
350mm
Axle
Small wheel side weight cast steel bridge
Small wheel side weight cast steel bridge
Middle wheel steel bridge
Large wheel steel bridge
Tire
20.5/70-16
20.5/70-16
20.5/70-16
16/70-20
Gantry width
160mm
160mm
180mm
180mm
Overall weight
4000kg
4200kg
5000kg
5500kg
Engine power
40kw
42KW
76KW
76KW
Gradeability
≤38°
≤38°
≤38°
≤38°
Rated lifting height
3000-6000mm
3000-6000mm
3000-6000mm
3000-6000mm
Front ground clearance
250-350mm
250-350mm
300-380mm
300-380mm
Drive type
4-wheel drive
4-wheel drive
4-wheel drive
4-wheel drive
Gearbox
265 Double high and low speed large pump torque converter
265 Double high and low speed large pump torque converter
280 Double high and low speed torque converter
280 Double high and low speed torque converter
Frame
Hinged thick 3mm
Hinged thick 3mm
Hinged thick 3.5mm
Hinged thick 3.5mm
For More Information Please Contact Our Sales Consultant √Looking Forward To Your InquiryWe Pay More Attention To Details, Details Are Our Quality
1.Intelligent Anti-Rollover Protection
Adopt intelligent control technology to detect equipment's real-time working parameters and prevent rollover operation. It is highly intelligent, ensuring safety and worry free operation.
Cargo Fall-off Protection Technology
The technology can automatically control the position of the attachment, preventing cargo fall in emergencies such as sudden brake or making a turn.
2.Automatic Fire Extinguishing Technology
The pipeline network automatic fire extinguisher with strong spray can realize fire alarm, anti-flaming and fire extinction functions. The fireproof performance is steady and reliable.
3.Cab Automatic Lock Technology
While under maintenance, the cab will be turned on one side. With inappropriate operation, accidents would happen. Cab of heavy-duty forklift truck has the double protection of mechanical and hydraulic anti-rollover protection, effectively preventing accidental rollover.
4.Automatic Braking Technology upon Reversing
Adopting technologies like laser scanning and graphic identification, the machine can precisely detect people or obstacles within the driving route and then brakes automatically to prevent accidents. It is highly intelligent with high safety.
5.Reliable Structure Design
Designed by China and Germany together, the equipment is assured to be highly reliable and endurable by adopting full-digit prototype design system, going through FEA, dynamics simulation analysis, as well as strict endurance and vibration tests.
We are a trustworthy companyOur company always pays attention to customer evaluation. The picture below is the unanimous praise of our customers worldwide.
Committed to creating high-quality services, becoming an enterprise trusted by customers, proud of employees, and respected by society.
Realize customer dreams and continue to create maximum value for customers
FAQ
1. Are you a manufacturer?
Yes, we are a manufacturer, we have our own factory. And we are the top supplier in China. We promise that we are exactly the
supplier you have been looking for. We welcome you to visit our factory to check our production lines and know more about our capacity, quality.
2. Do you have quality control system?
Yes, we have ISO, CE and our own quality control team. And we will do a lot of different tests to make sure it works fine
3. Can you arrange the shipment for us?
Yes, we have appointed shipping and rail freight forwarders with decades of experience, and we can get the best prices through designated vessels and professional services.
4. How long is your delivery time?
Generally it is 7-14 days, we have the Machinery in our stock.
5. Can you reduce the price?
Yes, we have some discount for new customers, you will get the best quality and price from me.
6.How do you keep long-term business and good relationship ?
(1)We keep supplying good quality products and competitive prices to ensure our customers' benefit.
(2)We think highly of every single customers of us and value the relationship, we take it not only as business partner, but also as true friends. Will keep the good services and put customers' benefit as high priority.
(3)My job is to help customers buy the highest quality machinery at the best price.
(4)Our goal is to help customers save money and help customers make money.
Why not to have a try to send inquiry below to us?
We promise you will be satisfied by our outstanding quality and favorable price.
Please contact for more information!
Our Vision: To be world-class professional, reliable and outstanding machinery supplier.
Our Mission: Offer best services, be the best choice.
Our Value: Honest and trustworthy, pursuing sustainable development.
