• Model NO.：TFZ16
• Lift height：3m-11m
• Condition：New
• Product Name：1.5t Electric Reach Forklift Truck
• Loading Capacity：1500kg
• Lifting Height：Duplex Mast, Triple Mast
• Battery：48V
• Controller：USA Curtis
• Fork Length：1070mm, 1150mm, 1220mm
• Wheel：PU
• Charger：Included
• Color：Customized
• Camera&LCD Display：Optional
• Transport Package：Standard Packing
• Specification：2260*1080*2260MM
• Trademark：Noelift
• Origin：China
• HS Code：842710
• Production Capacity：80PCS,Year

Description
Model No.

TF15-30

TF20-30

TF25-30

Rated Capacity (KG)

1500

2000

2500

Operate Type

Stand-on

Stand-on

Stand-on

Max. Lifting Height (MM)

3000

3000

3000

Min. Turning Radius (MM)

1625

1965

1965

Min. Stacking Aisle---mm (1000*1000 Pallet)

2622

2895

2895

Max Travel Speed km/h-laden/unladen

7.5/8.5

7.0/8.0

7.0/8.0

Load center MM

500

500

500

Fork Dimensions-L/W/T---mm

1070*100*35

1070*100*45

1070*100*45

Max. Gradeability ---%

10

10

10

Lifting Speed (MM/S)-laden/unladen

117/243

110/243

110/243

Overall Length (MM)

2266

2468

2468

Overall Width (MM)

1098

1258

1258

Height-Overhead guard--mm

2320

2320

2320

Height---Mast Lowered(MM)

2080

2084

2084

Height-Mast Extended w/ Load-Backrest -mm

3885

3875

3875

Height--Free Lift --mm

100

100

100

Tilt Angle----Upward/Downward--deg.

3/5

3/5

3/5

Fork Spread Range (MM)

220-662

247-780

247-780

Reach Stroke

560

685

685

Min Ground Clearance--mm

80

80

80

Wheel Type

Polyurethane Solid Tyre

Driving Wheel (MM)

Φ343×108

Φ343×108

Φ343×108

Balance Wheel (MM)

Φ180×76

Φ180×76

Φ180×76

Front Wheel (MM)

Φ267×114

Φ267×114

Φ267×114

Battery V/AH- "TONGBA"BRAND

48V /300 AH

48V/400 AH

48V/400 AH

Service Brake

MECH.

Parking Brake

MECH.

Charger-Intelligent

48V/40A

48V/50A

48V/50A

Driving Motor (KW)

5.5 (AC)

5.5 (AC)

5.5(AC)

Lifting Motor (KW)

6.3

7.5

7.5

OUR FACTORY


our service

1. OEM Manufacturing welcome: Product, Package...
2. Custoner order
3. We will reply you for your inquiry in 12 hours.
4. after sending, we will track the products for you once every two days, until you get the products. When you got the
    goods, test them, and give me a feedback.If you have any questions about the problem, contact with us, we will offer
    the solve way for you..
