2.5t LPG Psi Cushion Tire Forklfit with 4G64 Engine
ROYAL FORKLIFT (SUZHOU) CO., LTD.- Cab Location：Suspension
- Type：LPG Forklfit
- Power：LP Gas Engine
- Load Capacity：2-3.5t
- Fuel：Natural Gas
- Load center：500mm
Base Info
- Model NO.：C25Z
- Lift height：3000-6500mm
- Condition：New
- Color：Red,Yellow,Ice Blue,Orange
- Engine：4G64
- Transport Package：Bubble Bag Packing, Tire Fix in Container
- Specification：psi standard
- Trademark：Royal
- Origin：China
- HS Code：84272090
- Production Capacity：3000
Description
Manufacturer RY RY RY RY MODEL C20HG C25HG C20HG C25HG General Power Type GASOLINE / GASOLINE&LPG/ LPG engine 4G64 Rated Load Capacity kg 2000 2500 3000 3500 Load Centre mm 500 Characteristic & Dimension Rated Lift Height mm 3000 Free Lift Height mm 140 145 150 Mast Tilt Angle (F/R, α°/β°) Deg 6º/12º Mast Lowered Height mm 2045 2060 Mast Extended Height (With Backrest) mm 4145 4160 Overhead Guard Height mm 2180 2192 Ground Clearance (Bottom of Mast) mm 130 145 Length to Face of Fork (Without Fork) mm 2625 2716 2780 Overall Width mm 1150 1225 Fork Size (L×W×T) mm 1070×125×40 1070×125×45 Fork Overhang (Wheel Center to Fork Face) mm 473 478 Rear Overhang mm 508 578 642 Turning Radius (Outside) mm 2315 2420 2490 Min.Right Angle Stacking Aisle Width
(Add Load Length and Clearance) mm 4010 4120 4190 Performance Travel Speed (No Load) km/h 20 Travel Speed (Full Load) km/h 19 18.5 Lifting Speed (Full Load) mm/s 490 390 360 Lowering Speed (Full Load) mm/s 450 Max.Drawbar Pull (Full Load) KN 22/18 Max.Gradeability (Full Load) % 20 Service Brake (Operation/Control) Foot/Powershift Parking Brake (Operation/Control) Hand/Mechanical Chassis Tyre (Front x 2) 7.00-12-12PR 28X9-15-12PR Tyre (Rear x 2) 6.00-10-10PR 6.50-10-10PR Front Tread mm 970 1000 Rear Tread mm 980 Wheelbase mm 1650 1700 Weight Total Weight kg 3450 3620 4310 4750 Front Axle Weight Distribution (Full Load) kg 4856 5372 6490 7320 Rear Axle Weight Distribution (Full Load) kg 594 748 820 930 Front Axle Weight Distribution (No Load) kg 1507 1492 1764 2040 Rear Axle Weight Distribution (No Load) kg 1943 2128 2546 2710 Option air cleaner double air filter/air cleaner seat suspention seat/ grammer seat tyre solid tyre/ no-marking solid trye/double solid tyre exhaust system vertical exhaust air condition fans/heater/air condition safe operate tools fir extinguisher attachment sideshifter/fork positioners/paper roll clmps/push&pulls/specialty products cabin rain top roof/only front glass/Half closed cabin/complete capin mast duplex 3.0m-6.0m duplex full free 3.0m-4.0m triplex 4.3m-6.5m
