• Model NO.：FG25
• Load center：500mm
• Lift height：3000mm
• Condition：New
• Fork Size：1070*122*40mm
• Weight：3580kg
• Engine：Nissan Engine
• Color：Customized
• Tire Type：Pneumatic
• Free Lift：160mm
• Item：2.5 Ton LPG Forklift
• Wheelbase：1600mm
• Standard Lifting Height：3m
• Transport Package：Container
• Specification：2530*1150*2120mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：800sets,Year

Manufacturer                          LTMGModel                                   Power shift T/M         FG25Manual shift T/M    FG25Load capacity                        kg2500Load center mm500Power unit   Gasoline/LPGOperator type  Driver/seat Tire type    Front/rear PneumaticWheel Front/rear 2/2Max. lifting height                   mm3000Free lift                       mm160Fork size       L*W*Tmm1070*122*40Tilt range                               Mast forward/backward             deg6/12Overall length(without fork)     mm2530Total width   mm1150Mast height (fork lowering)    mm1995Overall height fork raised      With backrest                             mm4030Height to head guard              mm2120Turning radius(outside)           mm2240Front face of fork to front axle mm450Min. right angle stacking aisle  without load length&clearance                    mm2690SpeedMax Travelling         full/no loadkm/h17/19Lifting              full/no load        mm/s550/580Lowering         full/no load                    mm/s450/550Max.drawbar pull                  Power shift T/M      full/no load                                      kg1650/830Manual shift T/M       full/no load                                kg1700/830Gradeability at 1.6km/h         Power shift T/M      full/no load                                      %22/18Manual shift T/M       full/no load                                          %22/18Truck weight  kg3580Weight  distributionFull  load              front/rear        kg5370/710No  load               front/rear      kg1390/2190Tires                                      Numberfront/rear2/2Modelfront axle 7.00-12-12PRrear axle6.00-9-10PRWheelbase                              mm1600Tread    Front/rearmm970/970Ground clearance                 At lowest point(mast)                 mm110Framemm115Brake                                           Service  brake Hydraulic-foot pedal                                            Parking brake Mechanical-hand lever                                        Battery                                         Voltage/capacityV/AH12/60Engine                                         Model Nissan K21Rated powerPS(kw/rpm)47/2250(34.6/2250)Rated torquekg-m    max.(N.m)15.7/1600(153/1600)Number of cylinders 4PlacementL2.065Fuel tank capacityL70Transmission    Speed forward/backward          Power shift T/M Manual shift T/M    1-1 power shift T/M2-2 manual shift T/M                                             Operating pressure                   Hydraulic system pressure         kg/cm²180
