• Model NO.：FD30
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070mm*125mm*45mm
• Weight：4380kg
• Engine：Chinese Engine,Isuzu,Mitsubishi
• Wheelbase：1700mm
• Color：Decided by Buyer
• Max.Lifting Height：3000mm
• Rated Power：34.3kw,2500rpm
• Tire：Pneumatic Tyre or Solid Tyre
• Mast：2 Stage Mast or 3 Stage Mast
• Optional：Side Shifter, Fork Positioner,Cab with A,C
• Transport Package：Container
• Specification：2705mm*1225mm*2140mm
• Trademark：LTMG
• Origin：China
• HS Code：8427209000
• Production Capacity：1000sets,Year

The specification of LTMG Diesel Forklift Truck 3 Ton ModelUNITFD30FD35PerformancePower Unit DieselDieselOperator Type Driver/seatDriver/seatRated CapacityKg30003500Load Centermm500500Max. Lifting Heightmm30003000Mast Tilting Angle (Fwd/Bwd)Deg6/126/12Free Lift Heightmm145150Turning Radiusmm23952415Lifting Speed (Loaded/Unloaded)mm/s480/500400/450Lowering Speed (Loaded/Unloaded)mm/s420/400400/370Travelling Speed (Loaded/Unloaded)Km/h20/2120/21Max. Gradeability (Loaded)%2121Max. Drawbar Pull (Loaded)N1717DimensionsOverall length (without fork)mm27302770Overall Widthmm12201220Overhead Guard Heightmm21452145Fork Size (LxWxT)mm1070X125X451070X125X45Mast Height (Fork lowered)mm20952175Truck WeightKg42504500Tyre Size (Front/Rear)  28×9-15-14PR/6.5-10-10PR28×9-15-14PR/6.5-10-10PREngineBrand  ISUZUXINCHAIISUZUXINCHAIModel  C240C4904JG2C495Rated PowerKw/rpm35.4/250035.4/250040/265042/2650Rated torqueN-m/rpm137.7/1800160/1600186/1800174/1600Number of cylinder  4444Displacement  2.362.673.062.8
Product Features:

-Adopt TCM type transmission, steering axle

- Isuze engine and Mitsubishi engine are optional

-Equipped with famous brand parts, like Shimadzu pump and valve, Eaton pipe, Nok hydraulic cylinder seals, Toyota seat with safety belt, cooper tank and so on

-Attachments can be equipped as customer's requirements, such as paper roll, forklift rotator, clamp etc.
The most reasonable system matching after repeated verification
After 400 hours of continuous enhancement test
Adopt gradeability improving style transmission, compare with other models
Load sensing priority steering hydraulic system is adopted to reduce pressure loss of hydraulic system



Packing and Shipping




Our Factory



Our customers

Our LTMG Forklift is widely used in the port, wharf, industrial and mining enterprises, station, warehouse, and others.
The quality of our LTMG forklift has been recognized by our customers.

After sales service

LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.

All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Detail clauses and policies please check our website and product certificate.
