Royal Heavy Duty Forklift 5t/6t/7t/10 Ton Forklift with Mitsubishi Engine
ROYAL FORKLIFT (SUZHOU) CO., LTD.- Cab Location：Adjustable
- Type：Ordinary Combustion Forklift
- Power：Diesel Engine
- Load Capacity：5T - 10T
- Fuel：Diesel
- Load center：600
Base Info
- Model NO.：H50b
- Lift height：3000mm-6500mm
- Condition：New
- Battery：24V,90ah
- Engine Manufacturer：Chaochai,Mitsubishi
- Fuel Tank Capacity：120L
- Transmission Type：Powershift
- Transport Package：Standard Export Packing
- Trademark：Royal
- Origin：China
- HS Code：84272090
- Production Capacity：1000PCS,Year
Description
Manufacturer RY RY RY MODEL H50 H60 H70 General Power Type DIESEL engine MITSUBISHI/CHAOCHAI Rated Load Capacity kg 5000 6000 7000 Load Centre mm 600 Characteristic & Dimension Rated Lift Height mm 3000 Free Lift Height mm 205 210 Mast Tilt Angle (F/R, α°/β°) Deg 6º/12º Mast Lowered Height mm 2500 2625 Mast Extended Height (With Backrest) mm 4420 Overhead Guard Height mm 2485 Ground Clearance (Bottom of Mast) mm 200 Length to Face of Fork (Without Fork) mm 3530 3620 Overall Width mm 1995 Fork Size (L×W×T) mm 1220X150X55 Fork Overhang (Wheel Center to Fork Face) mm 585 Rear Overhang mm 670 Turning Radius (Outside) mm 3290 3370 Min.Right Angle Stacking Aisle Width
(Add Load Length and Clearance) mm 5215 5315 Performance Travel Speed (No Load) km/h 28 Travel Speed (Full Load) km/h 26 Lifting Speed (Full Load) mm/s 400 330 Lowering Speed (Full Load) mm/s 500 Max.Drawbar Pull (Full Load) KN 45 43 Max.Gradeability (Full Load) % 32 27 24 Service Brake (Operation/Control) Foot/Powershift Parking Brake (Operation/Control) Hand/Mechanical Chassis Tyre (Front x 2) 8.25-15-14PR Tyre (Rear x 2) 8.25-15-14PR Front Tread mm 1470 Rear Tread mm 1700 Wheelbase mm 2250
