• Model NO.：FB30
• Lift height：3000~5000mm
• Condition：New
• Weight：4660kg
• Fork Size：1070mm*125mm*45mm
• Wheel Base：1600 mm
• Tilt Range(F/B)：6,12 Deg
• Gradeability：12.5
• Max.Lifting Height：3000 mm
• Wheel(F/B)：2,2
• Ground Clearance：120 mm
• Tire：Pneumatic
• Turning Radius：2140 mm
• Transport Package：Container
• Specification：2510mm*1225mm*2075mm
• Trademark：LTMG
• Origin：China
• HS Code：8427109000
• Production Capacity：800sets,Year

Manufacturer   LTMGModel     FB30Load capacity    kg3000Load center mm500Power unit   BatteryOperator type   Driver/seat         Tire type   Pneumatic                  Wheel(x=driving)  Front/rear 2X/2Max. lifting height    mm3000Free lift    mm165Fork size L*W*Tmm1070*125*45Tilt range     Mast forward/backward deg6/12Overall length(without fork)  mm2510Total width  mm1225Mast height (fork lowering) mm2075Overall height fork raised With backrest mm4250Height to head guard mm2190Turning radius(outside) mm2140Load distance mm480Min. right angle stacking aisle not add load length&clearancemm2625Speed  Max Travellingfull load km/h13.5Max Travellingno loadkm/h15Liftingfull load mm/s240Liftingno load mm/s450Gradeability    full load%12.5Truck weight(with standard battery) kg4660Weight  distribution Fullloadfront/rear  kg6770/890Noloadfront/rear kg1885/2775TiresNumber           front/rear  2/2Model  front axle  28*9-15-12PRrear axle18*7-8-14PRWheel base  mm1600Tread    Front/rearmm1000/950Ground clearance  At lowest point(mast)mm140Frame mm120Brake Service brake   Hydraulic-foot pedal  Parking brake Mechanical-hand lever  BatteryVoltage/capacity  V/AH/5hr72V-480Weight with box (standard)kg 1220Electric motor    AC Driving motor  kw16.6DC Hydraulic driving motor  kw10 AC Hydraulic driving motor (as option)kw13.4Control type Driving AC  , lifting DC
Driving AC  , lifting AC
(as option ) Operating pressure kg/cm²175

After sales service

Nowadays we have been sell more than 100 countries. All the products of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product's quality certificate.
