• Model NO.：SH60
• Condition：New
• Load Capacity (T)：6t
• Power Type：Diesel
• Fork Thickness：60mm
• Backrest Height：1365mm
• Fork Length：1220mm
• Max. Lifting Speeds ( with Load ) mm/S：330
• Max. Driving Speeds ( with/Without Load：22,26
• Max. Towing ( with/Without Load ) Kn：53
• Gradeability (with/Without Load ) %：20,27
• Min. Turning Radius (mm)：3250
• Transport Package：Container, FCL,LCL
• Specification：CE
• Trademark：sinoheng
• Origin：Shandong, China
• Production Capacity：300PCS,Month

Product Name6 Ton Diesel Forklift TruckModelSH60Load capacity (kg)6000Load center (mm)500Power typeDieselMax. lifting speeds ( with load )  mm/s330Max. driving speeds ( with/without load )  km/h22/26Max. towing ( with/without load )  kn53Gradeability (with/without load )  %20/27Lifting height (mm)3000Free lift (mm)210Tilting angles ( forward-backward )  (  .)6/12Min. turning radius (mm)3250Min. right angle aisel width ( mm )3090Min. under-clearance (mm)230
DimensionOverall length (including fork)mm4735Overall width ( mm )1995Overall height (mast lowered )mm2500Overall height (mast extend )mm4420Overall height to overhead guard (mm)2420Fork overhang (mm)590Wheel base (mm)2250TreadFront tread (mm)1470Rear tread (mm)1700TyreFront tyre8,25-15-14Rear tyre8,25-15-14Total weight (kg)8640Fork width (mm)150Fork thickness (mm)60Backrest height (mm)1365Fork length (mm)1220

EngineEngine modelChaochai6102-BGQC4112GRate power (KW)80.9/70Rotate speed at Rate power (rpm)2500/2300Max. torque  (nm)353/370Rotate speed at max torque (rpm)1650/1600-1800Battery2-12 V/80AHType of power shiftTor-non
