• Model NO.：ERB15
• Condition：New
• Fork Size：1150mm180mm*60mm
• Item：Stacker
• Max. Lifting Height：3000mm
• Controller：Curtis
• Max.Lifting Height：3000mm
• Overall Length：1940mm,2360mm
• Battery Capacity：24ah
• Optional：Side Shift, Battery Capacity
• Transport Package：Container
• Specification：1940mm*850mm*2000mm
• Trademark：LTMG
• Origin：China
• HS Code：8428109000
• Production Capacity：1000sets,Year

 Model ERB15 Type wide legsMast type 2-Stage STDLoad capacitykg1500 Load centermm600Wheel basemm1325Operating type  Walkie/Stand onWheel type PUWheel quantity driving wheel/
Balance wheel/Bearing wheel 1/2/4 Standard lift heightmm3000 Lowered fork heightmm85 Fork size(length/width/thickness)mm1150(1200)/180/60 Overall lengthmm1940/2360 Overall widthmm850Outside with between legsmm570/600/650/685 Inside with between legsmm180/230/280/315 Min.turning radiusmm1630/1990Min.aisle width for pallets 800×1200mm2180/2580Min.aisle width for pallets 1000×1200mm2210/2600Min.groud clearancemm30Travel speed,laden/unladenkm/h5/6 Lift speed,laden/unladenmm/s95/130 Travel speed,laden/unladenmm/s110/100radeability,laden/unladen%5/8 Battery voltageVAC1.5/DC3.0/DC0.15 Battery capacityAh24 Brake 240Controller CURTIS Battery weightkg235 Service weight with batterykg1190
