• Model NO.：SRSC45H
• Fuel：Diesel
• Load center：>500mm
• Lift height：>5000mm
• Condition：New
• Max. Lifting Capacity：45000kg
• Max. Lifting Height：15100mm
• Min. Turning Radius：8.1m
• Curb Mass：70995kg
• Wheel Base：6000mm
• Track (Front Wheel/Rear Wheel)：3024,2750mm
• Power/Rotation Speed：250,2100kw,R,Min
• Min. Ground Clearance：365mm
• Steering Mode：Rear Axle Steering
• Max. Hoisting Speed (Without/with Load)：350,200mm,S
• Max. Lowering Speed (Without/with Load)：330,260mm,S
• Max. Travel Speed (Without/with Load)：27,23km,H
• Drive Mode：4*2, Front Axle Drive
• Transport Package：Nude Package
• Specification：11295*6052*4489mm
• Trademark：CRUKING
• Origin：China
• HS Code：84295100
• Production Capacity：100unit,Month

Product ParametersItemUnitParameters
Lifting performanceMax. lifting capacitykg45000Stacking capacity--5-5-4Max. hoisting speed (without/with load)mm/s350/200Max. lowering speed (without/with load)mm/s330/260Max. lifting heightmm15100

Traveling performanceMax. travel speed (without/with load)km/h27/23Drive mode--4×2, Front axle driveMax. grade-ability%30%Min. turning radiusm8.1Steering mode--Rear axle steeringWeightCurb masskg70995
DimensionOutline dimension (L×W×H)mm11295×6052×4489Wheel basemm6000Track (front wheel/rear wheel)mm3024/2750Min. ground clearancemm365Approach angle/Departure angle°17.5/26.5


Power

EngineModel--QSMPower/rotation speedkW/r/min250/2100
Emission standard
--Off-road U.S.EPA Tier3, EU Stage IIIATransmissionModel--5WG261Gear--FWD 5, REV 3Drive axleModel--D102PL241Detailed Photos
