1t - 5t Duel Fuel Ltmg Side Shifter LPG Forklift

Xiamen LTMG Machinery Co., Ltd.
  • After-sales Service：1 Year,2000 Working Hours
  • Warranty：1 Year or 2000 Working Hours
  • Cab Location：Not Adjustable
  • Type：LPG&Gasoline Forklift
  • Power：Gasoline Engine
  • Load Capacity：1T - 5T

Base Info

  • Model NO.：FG30
  • Fuel：Gasoline
  • Load center：500mm
  • Lift height：3000~5000mm
  • Condition：New
  • Power Type：LPG&Gasoline
  • Fork Size：920*120*35mm
  • Weight：2820kg
  • Wheelbase：1400mm
  • Tire Type：Pneumatic
  • No. of Cylinder：4
  • Transmission：Hydraulic
  • Color：Customize
  • Transport Package：Container
  • Specification：2245mm*1070mm*2060mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427209000
  • Production Capacity：800sets,Year

Description

ModelFG15FG20FG25FG30FG35Rated Capacity1500kg2000kg2500kg3000kg3500kgLoad Centre500mm500mm500mm500mm500mmLift Height3000mm3000mm3000mm3000mm3000mmFork Size920×120×351070×120×401070×120×401070×125×451070×125×50Length to face of fork(Without fork)2285mm2355mm2355mm2730mm2775mmOverall Width1086mm1110mm1110mm1225mm1225mmOverhead Guard Height2040mm2080mm2080mm2090mm2090mmTurning Radius (outside)2055mm2110mm2110mm2440mm2480mmWheelbase1400mm1400mm1400mm1700mm1700mmEngineGCTGCTGCTGCTGCTModelFG40FG45FG50FG60FG70Rated Capacity4000kg4000kg5000kg6000kg7000kgLoad Centre500mm500mm600mm600mm600mmLift Height3000mm3000mm3000mm3000mm3000mmFork Size1070×125×501070×125×501220×150×601220×150×601220×150×70Length to face of fork(Without fork)2890mm2890mm3440mm3440mm3565mmOverall Width1410mm1410mm2010mm2010mm2010mmOverhead Guard Height2120mm2120mm2430mm2430mm2430mmTurning Radius (outside)2700mm2700mm3250mm3250mm3350mmWheelbase1900mm1900mm2250mm2250mm2250mmEngineGCTPSIPSI PSI PSI
