Forklifts & Parts

Home > Product > Forklift

Ltmg Reach Forklift Truck 2.5 Ton Electric Reach Stacker for Sale

XIAMEN LTMG CO., LTD.
  • Cab Location：Not Adjustable
  • Type：Stacker
  • Power：AC Motor
  • Load Capacity：2500kg
  • Fuel：Electric
  • Load center：500mm

Base Info

  • Model NO.：FRB25
  • Lift height：3000~5000mm
  • Condition：New
  • Certificate：ISO Ce
  • Fork Size：1070mm*122mm*40mm
  • Warranty：1 Year,2000 Working Hours
  • Color：Customize
  • Max.Lift Capacity：2500kg
  • Max. Gradeability：10%
  • Operator Type：Standing Type
  • Max.Lift Height：3000mm
  • Truck Weight(Without Battery)：2385kg
  • Wheelbase：1700mm
  • Product Name：Ltmg Reach Forklift 2.5 Ton Electric Reach Truck F
  • Product Type：Electric Reach Truck
  • Transport Package：Container
  • Specification：2468mm*1258mm*2320mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427109000
  • Production Capacity：800set,Years

Description

The specification of 2.5 ton electric Reach Forklift truckModel No.FRB25Rated Capacity (KG)2500Operate TypeStand-onMax. Lifting Height (MM)3000Min. Turning Radius (MM)1965Min. Stacking Aisle---mm (1000*1000 Pallet)2895Max Travel Speed km/h-laden/unladen7.0/8.0Load center MM500Fork Dimensions-L/W/T---mm---8.1070*122*40Max. Gradeability ---%10Lifting Speed (MM/S)-laden/unladen117/243Overall Length (MM)2468Overall Width (MM)1258Height-Overhead guard--mm2320Height---Mast Lowered(MM)2084Height-Mast Extended w/ Load-Backrest -mm3920Height--Free Lift --mm100Tilt Angle----Upward/Downward--deg.3/5Fork Spread Range (MM)220-662Reach Stroke685Min Ground Clearance--mm80Wheel TypePolyurethane Solid TyreDriving Wheel (MM)Φ343×108Balance Wheel (MM)Φ180×76Front Wheel (MM)Φ267×114Battery V/AH- "TONGBA"BRAND48V /300 AHService BrakeMECH.Parking BrakeMECH.Charger-Intelligent48V/40ADriving Motor (KW)5.5 (AC)Lifting Motor (KW)7.5



Product Features

1. Safety Device for neutral position to increase the safety of forklift;

2. High Strength frame to protect the operator;

3. Oil-way stop Valve,to protect the operator and goods;

4. AC electric controller with multiple automatic safety protection settings, to reduce the operation accident by misoperation;

5. Inching capacity, the forklift can finish the extremely adjustment during moving;

6. With Imported AC motor without Carbon brush, dustproof, damp proofing,long working life, lower use-cost, controlled voltage/frequency;

7. To use water-proof and dust-proof design for all circuit, to aviod the shortcircuiting happened;

8. To use intelligent charger, auto analysis the residual energy and optimizing the charging process, without manual operation and extend the battery working life effectivly;

9. High Speed Limited, the forklift will reduce the lift speed when lift to a high position;

10. High Strength overhead guard to protect the operator.


Packing & Delivery

Ltmg Reach Forklift Truck 2.5 Ton Electric Reach Stacker for Sale

After-sale service

LTMG always treat after-sale service as important as sale. Nowadays more than 50 agents around the world can supply LTMG professional after-sale service.

All the product of LTMG supplied with one year or 2000 working hours (which occurs first) period quality warranty.

Detail clauses and policies please check our website and product certificate.

Ltmg Reach Forklift Truck 2.5 Ton Electric Reach Stacker for Sale
Ltmg Reach Forklift Truck 2.5 Ton Electric Reach Stacker for Sale

FAQ

1. What Certificate do you have?
LTMG workshop meet with the ISO9001:2008 Quality System.
All of our products with CE certificate.  Some of our products meets the EPA requirements.
LTMG never recruit Underage labor.

2. Can you customize and design as the clients' requirement?
LTMG will try its best to meet all kinds of clients' special requirements.
However, All the customizing and refit should be implemented safely and scientifically.
The colors can be painted as client's need.

3. How long is the warranty of your products?
Normally 1 year or 2000 working hours whichever occurs first. Details to see the LTMG warranty policy for each model.

4. Can you produce the products labeled with the client's brand?
With the authorization of the brand, we can OEM for our clients.

5. What payment terms do you accept?
Normally 30% T/T in advance as deposit, balance paid before shipment.
100% L/C at sight issued by world famous bank with good faith is also available.

6. Delivery time:
Standard configuration products are always in stock.
The production period of Customizing products is 30 days.
