• Model NO.：FD35T
• Fuel：Diesel
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Fork Size：1070X125X50mm
• Tyre Type：Pneumatic
• Wheelbase：1700mm
• Travel Speed：18km,H
• Lifting Speed：480mm,S
• Self Weight：4400kg
• Transport Package：Nude Packing
• Specification：2813*1225*2235mm
• Trademark：China top brand
• Origin：China
• HS Code：84272090
• Production Capacity：100units,Month

Overview Product DescriptionDetailed Photos



Product ParametersDieselRated Load CapacityQ(kg)3500Load CentreC(mm)500Rated Lift HeightH3(mm)3000Free Lift HeightH2(mm)100Fork Size (L×W×T)mm1070×125×50Mast Tilt Angle (F/R, α°/β°)deg6°/12°Fork Overhang (Wheel Center to Fork Face)X1(mm)484Rear OverhangX2(mm)635Ground Clearance (Bottom of Mast)H7(mm)145Length to Face of Fork (Without Fork)L1(mm)2813Overall WidthB1(mm)1225Mast Lowered HeightH1(mm)2070Mast Extended Height (With Backrest)H4(mm)4070Overhead Guard HeightH5(mm)2235Tyre (Front x 2)mm28×9-15-12PRTyre (Rear x 2)mm6.50-10-10PRTotal Weightkg4840BatteryV/Ah12/90
