• Model NO.：FD30(T)
• Fuel：Diesel
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Rated Capacity(Kg)：3000
• Load Centre(mm)：500
• Free Lifting Height(mm)：165
• Front Overhang(mm)：478
• Min.Turning Radius(mm)：2460
• Max.Gradient(%)：20
• Tread(Front/Rear)(mm)：1000,980
• Mast(mm)：130
• Mast Tilt Angle(Deg)：6,12deg
• Max,Lifting Speed(mm/S)(Load/Unload)：485,505
• Transport Package：Container
• Specification：3850*1250*2135mm
• Trademark：Lonking
• Origin：China
• HS Code：850110919
• Production Capacity：1000

ModelUnitFD20(T)FD25(T)FD30(T)FD35(T)CPC(D)20CPC(D)25CPC(D)30CPC(D)35Power type/dieseldieseldieseldieselRated  capacitykg2000250030003500J Load centermm500500500500H1  STD lifting heightmm3000300030003000H3  free lifting heightmm150150165170L5×W×T forke sizemm1070×120×401070×120×401070×125×451070×125×50Mast tilt angledegForward 6/Rear12Forward 6/Rear12Forward 6/Rear12Forward 6/Rear12L3  Front overhangmm460460479498L4 Rear  overhangmm410470522580DimensionL1 Overall length(with fork)mm3590365037703830W1 Overall widthmm1160116012251225h2 STD mast lower heightmm2000200020752180h4 OverHead guard  heightmm2110211021302130the height of Load-backrestmm97597512801280R1  Min. turning radiusmm2250230024602490Ra Min intersecting aislemm3900397041554200 Max travel speed(load/unload)Km/h18/2018/2018.5/2018.5/20 Max lifting speed(load/unload)mm/s550/530550/530505/485400/380Gradeablity(load/unload)%20202020Self weightkg3400380042204650tyrefront tires/7.00-12-12PR7.00-12-12PR28×9-15-14PR28×9-15-14PRRear tires/6.00-9-10PR6.00-9-10PR6.5-10-10PR6.5-10-10PRTreadS front tiresmm97097010001000P  Rar tiresmm980980980980L2  axle distancemm1650165017001700 Min.ground clearancem2  Mastmm110110130130m1 Framemm150150160160fuel  tank capacityltr50506060EngineModel/YunneiYN4A055-31CRxicahi4D27G31-007QuancahiC02-624Rated  capacitykW/r36.8/260036.8/250036.8/2500Rated  torqueN·m/r180/1600~1950156/1700~1900157/1800~1900cylinder number/444DisplacementL 2.672.672.67Detailed PhotosCompany Profile
