3.5 Tons Diesel Forklift with Original Japanese Yanmar Engine

ROYAL FORKLIFT (SUZHOU) CO., LTD.
  • Cab Location：Adjustable
  • Type：Ordinary Combustion Forklift
  • Power：Diesel Engine
  • Load Capacity：3.5t
  • Fuel：Diesel
  • Load center：500mm

Base Info

  • Model NO.：C35Y
  • Lift height：3000-6500mm
  • Condition：New
  • Engine Manufacturer：Isuzu,Mitsubishi,Xinchai,Yanmar,Nissan
  • Fuel Tank Capacity：50L
  • Transmission Type：Powershift
  • Option Tyre：Double Pneumatic,Solid Tyre,No Marking Solid Tyre
  • Option Attachment：Side Shifter,Fork Positioner,Drum Clamps
  • Option：Cabin, Air Condition
  • Transport Package：Standard Export Packing
  • Trademark：Royal
  • Origin：China
  • HS Code：84272090
  • Production Capacity：1000PCS,Year

Description

Manufacturer RY MODEL C35EC35DC35YGeneral Power Type DIESELengine MITSUBISHI  EuIIIXINCHAI EuIIIYANMARRated Load Capacitykg3500Load Centremm500Characteristic & DimensionRated Lift Heightmm3000Free Lift Heightmm145Mast Tilt Angle (F/R, α°/β°)Deg6º/12ºMast Lowered Heightmm2060Mast Extended Height (With Backrest)mm4160Overhead Guard Heightmm2198Ground Clearance (Bottom of Mast)mm145Length to Face of Fork (Without Fork)mm2716Overall Widthmm1225Fork Size (L×W×T)mm1070×125×45Fork Overhang (Wheel Center to Fork Face)mm478Rear Overhangmm578Turning Radius (Outside)mm2420Min.Right Angle Stacking Aisle Width
(Add Load Length and Clearance)mm4120PerformanceTravel Speed (No Load)km/h20Travel Speed (Full Load)km/h18.5Lifting Speed (Full Load)mm/s430Lowering Speed  (Full Load)mm/s450Max.Drawbar Pull (Full Load)KN16/15.716/15.717/16Max.Gradeability (Full Load)%20Service Brake (Operation/Control) Foot/PowershiftParking Brake (Operation/Control) Hand/MechanicalChassisTyre (Front x 2) 28x9-15-12PRTyre (Rear x 2) 6.50-10-10PRFront Treadmm1000Rear Treadmm980Wheelbasemm1700WeightTotal Weightkg3620Front Axle Weight Distribution (Full Load)kg5372Rear Axle Weight Distribution (Full Load)kg748Front Axle Weight Distribution (No Load)kg1492Rear Axle Weight Distribution (No Load)kg2128
3.5 Tons Diesel Forklift with Original Japanese Yanmar Engine
3.5 Tons Diesel Forklift with Original Japanese Yanmar Engine
3.5 Tons Diesel Forklift with Original Japanese Yanmar Engine
3.5 Tons Diesel Forklift with Original Japanese Yanmar Engine3.5 Tons Diesel Forklift with Original Japanese Yanmar Engine
