8 Ton Forklift Truck Factory Seller
Jinan Sinoheng Import and Export Co., Ltd.- Cab Location:Adjustable
- Type:Powered Pallet Truck
- Power:Diesel Engine
- Load Capacity:5T - 10T
- Fuel:Diesel
- Load center:500mm
Base Info
- Model NO.:SH80
- Lift height:>5000mm
- Condition:New
- Load Capacity (T):8t
- Power Type:Diesel
- Free Lift:195mm
- Lifting Height:3000mm
- Fork Width:170mm
- Fork Thickness:70mm
- Backrest Height:1374mm
- Transport Package:Container, LCL,FCL
- Specification:CE
- Trademark:sinoheng
- Origin:Shandong, China
- Production Capacity:300PCS,Month
Description
Product Name8 Ton Diesel Forklift Truck Model SH80 Load capacity (kg) 8000 Load center (mm) 600 Power type Diesel Max. lifting speeds ( with load ) mm/s 350 Max. driving speeds ( with/without load ) km/h 26/30 Max. towing ( with/without load ) kn 58 Gradeability (with/without load ) % 21/20 Lifting height (mm) 3000 Free lift (mm) 195 Tilting angles ( forward-backward ) ( .) 6/12 Min. turning radius (mm) 3700 Min. right angle aisel width ( mm ) 3310 Min. under-clearance (mm) 250
Dimension Overall length (including fork)mm 5160 Overall width ( mm ) 2165 Overall height (mast lowered )mm 2700 Overall height (mast extend )mm 4375 Overall height to overhead guard (mm) 2585 Fork overhang (mm) 700 Wheel base (mm) 2500 Tread Front tread (mm) 1600 Rear tread (mm) 1700 Tyre Front tyre 9.00-20-14 Rear tyre 9.00-20-14 Total weight (kg) 10960 Fork width (mm) 170 Fork thickness (mm) 70 Backrest height (mm) 1374 Fork length (mm) 1220
Engine Engine model Chaochai6102-BG Rate power (KW) 80.9 Rotate speed at Rate power (rpm) 2500 Max. torque (nm) 353 Rotate speed at max torque (rpm) 1650 Battery 2-12 V/80AH Type of power shift Tor-non
