• Model NO.：SH80
• Lift height：>5000mm
• Condition：New
• Load Capacity (T)：8t
• Power Type：Diesel
• Free Lift：195mm
• Lifting Height：3000mm
• Fork Width：170mm
• Fork Thickness：70mm
• Backrest Height：1374mm
• Transport Package：Container, LCL,FCL
• Specification：CE
• Trademark：sinoheng
• Origin：Shandong, China
• Production Capacity：300PCS,Month

Product Name8 Ton Diesel Forklift TruckModelSH80Load capacity (kg)8000Load center (mm)600Power typeDieselMax. lifting speeds ( with load )  mm/s350Max. driving speeds ( with/without load )  km/h26/30Max. towing ( with/without load )  kn58Gradeability (with/without load )  %21/20Lifting height (mm)3000Free lift (mm)195Tilting angles ( forward-backward )  (  .)6/12Min. turning radius (mm)3700Min. right angle aisel width ( mm )3310Min. under-clearance (mm)250
DimensionOverall length (including fork)mm5160Overall width ( mm )2165Overall height (mast lowered )mm2700Overall height (mast extend )mm4375Overall height to overhead guard (mm)2585Fork overhang (mm)700Wheel base (mm)2500TreadFront tread (mm)1600Rear tread (mm)1700TyreFront tyre9.00-20-14Rear tyre9.00-20-14Total weight (kg)10960Fork width (mm)170Fork thickness (mm)70Backrest height (mm)1374Fork length (mm)1220

EngineEngine modelChaochai6102-BGRate power (KW)80.9Rotate speed at Rate power (rpm)2500Max. torque  (nm)353Rotate speed at max torque (rpm)1650Battery2-12 V/80AHType of power shiftTor-non
