Mantacarga 6m Electric Forklift 2ton 3 Ton 3.5ton Forklift Electric with CE Certification

Xiamen LTMG Machinery Co., Ltd.
  • Cab Location：Adjustable
  • Type：Electric Forklift
  • Power：AC Motor
  • Load Capacity：1T - 5T
  • Fuel：Electric
  • Load center：500mm

Base Info

  • Model NO.：FB35
  • Lift height：3000~5000mm
  • Condition：New
  • Fork Size：1070mm*125mm*50mm
  • Weight：5190kg
  • Wheel Base：1600mm
  • Color：Yellow
  • Battery：72V
  • Ground Clearance：120mm
  • Load Distance：485mm
  • Tire：Pneumatic
  • Max. Lifting Height：3000mm
  • Truck Weight：5190mm
  • Transport Package：Container
  • Specification：2550mm*1225mm*2190mm
  • Trademark：LTMG
  • Origin：China
  • HS Code：8427109000
  • Production Capacity：800sets,Year

Description

Speed  Max Travellingfull loadkm/h13Max Travellingno load km/h14.5Liftingfull load mm/s220Liftingno loadmm/s450Gradeability full load%12.5Truck weight(with standard battery)  kg5190Weight  distribution Fulloadfront/rearkg7480/1210Noloadfront/rearkg2000/3190TiresNumber front/rear   2/2Model frontaxle 28*9-15-12PRrear axle     18*7-8Wheel base mm1600Tread  Front/rearmm1000/950Ground clearance   At lowest point(mast) mm140Frame mm120Brake Servicebrake Hydraulic-foot pedal Parking brake Mechanical-hand lever BatteryVoltage/capacity  V/AH/5hr72V-560Weight with box (standard) kg 1290Electric motorAC Driving motor       kw16.6DC Hydraulic driving motor kw13 AC Hydraulic driving motor (as option)kw13.4Control type Driving AC  , lifting DC
Driving AC  , lifting AC(as option )Operating pressure  kg/cm²175
