• Model NO.：FB25
• Load center：500mm
• Lift height：3000~5000mm
• Condition：New
• Weight：3820kg
• Wheelbase：1400mm
• Fork Size：1070mm*122mm*40mm
• Overall Length(Without Fork)：2285mm
• Color：Customized
• Max.Lifting Height：3000mm
• Load Distance：445mm
• Height to Head Guard：2145mm
• Transport Package：Container
• Specification：2285mm*1150mm*2145mm
• Trademark：LTMG
• Origin：China
• HS Code：8427109000
• Production Capacity：800sets,Year

Manufacturer  LTMGModel     FB25Load capacity  kg2500Load center  mm500Power unit   BatteryOperator type  Driver/seat    Tire type    PneumaticWheel(x=driving)Front/rear 2X/2Max. lifting height  mm3000Free lift mm160Fork size L*W*Tmm1070*122*40Tilt range Mast forward/backward deg6/12Overall length(without fork)  mm2285Total width       mm1150Mast height (fork lowering)    mm1995Overall height fork raised With backrest   mm4030Height to head guard mm2145Turning radius(outside) mm2000Load distance mm445Min. right angle stacking aislenot add load length&clearancemm2445SpeedMax Travellingfull loadkm/h13.5Max Travellingno loadkm/h14.5Lifting full load mm/s240Lifting no load  mm/s450Gradeabilityfull load   %12.5Truck weight(with standard battery) kg3820Weight  distributionFull load front/rear kg5425/895No load front/rear kg1425/2395Tires Numberfront/rear   2/2Model front axle  21*8-9-16PRrear axle    18*7-8-14PRWheelbase  mm1400Tread  Front/rearmm955/950Ground clearance At lowest point(mast)mm110Frame mm115Brake  Servicebrake  Hydraulic-foot pedalParking brake Mechanical-hand leverBattery  Voltage/capacity    V/AH/5hr48V-450Weight with box (standard)kg 825Electric motor  AC Driving motor  kw11DC Hydraulic driving motor  kw8.6 AC Hydraulic driving motor (as option)   kw13Control type  Driving AC  , lifting DC
Driving AC  , lifting AC(as option ) Operating pressure kg/cm²175
Product Features

1.Equipped with original imported American Curtis electric control system; High voltage and large capacity battery can supply the forklift with strong power; DC or AC motors are optional according to customers' requirements.
2.Designed to work in the rain, electric forklift can be used in various kinds of wet and dry environments.
3.Ergonomics Adjustable seat:Designed according to the ergonomic principles, make the operation much comfortable and also relieves the fatigue caused by long continuous operation.
4.Bigger and non-slip step make operating convenient and safe.
5.The standard LED lamps and warning lights make it safer ,more energy efficient and create better working condition

Packaging&Shipping

After sales service

LTMG always treat after-sale service as important the same as product quality.

LTMG grants our clients a twelve-month-period or 2000 working hours warranty for any machine purchased from us.

LTMG can also help clients coordinate with trained service personnel to provide you detailed and extensive knowledge about your specific machine. With our technical advises, your machine service life can be significantly prolonged and sustained with high capacity.
